GE IS200DTAOH1ABA IS210DTAOH1AA 涡轮控制器系统燃机模块

GE IS200DTAOH1ABA IS210DTAOH1AA 涡轮控制器系统燃机模块

产品介绍

使用九个光纤镜头选项，三个聚合物螺栓探头，12个玻璃和石英组件，100到1600?C (212 ~ 2912?F)温度范围。该系列具有多种标准功能，如可调发射率，线性模拟输出，高低报警电压输出，RS232 PC接口，内置激光瞄准具等。通过基于windows的PC机界面软件，用户可以选择响应时间、峰值保持功能、高低报警设置和数据记录。OS4000系列封装在63.5 (OD) x 152.4 mm (L) (2.5 x 6”)的节省空间的外壳中。

规格:

电源:15 ~ 24vdc

温度范围:100 ~ 1600?C (212 ~ 2912?F)

准确度:读数的1%

透镜探头光场:5.6@203mm (0.22@8 ")， 2.2@127mm (0.086@5 ")， 0.63@51mm (0.025@2 ")

光缆长度:0.3、0.9、1.8、3m(1、6、3、10′)

发射率:0.05 ~ 0.99，可调

Product introduction

Model name: IS200DTAOH1ABA analog output module

Using nine fiber optic lens options, three polymer bolt probes, and twelve glass and quartz components, 100 to 1600?  C (212 ~ 2912?  F) Temperature range.  The series has a variety of standard features such as adjustable emissivity, linear analog output, high and low alarm voltage output, RS232 PC interface, built-in laser sight and more.  Through the Windows-based PC interface software, users can choose response time, peak hold function, high and low alarm Settings, and data logging.  The OS4000 series is packaged in a space-saving housing of 63.5 (OD) x 152.4 mm (L) (2.5 x 6").

Specifications:

Power supply: 15 ~ 24 Vdc

Temperature range: 100 ~ 1600?  C (212 ~ 2912?  F)

Accuracy: 1% of reading

Optical field of lens probe: 5.6@203mm (0.22@8 "), 2.2@127mm (0.086@5 "), 0.63@51mm (0.025@2 ")

Fiber cable length: 0.3, 0.9, 1.8, 3 m (1, 6, 3, 10')

Emissivity: 0.05 ~ 0.99, adjustable
