产品说明

IS220PTURH1A是GE为其Mark VI系统开发的组件。Mark VI是GE发布的用于燃气/蒸汽轮机管理的终Speedtronic系统之一。

IS220PTURH1A是一次汽轮机专用一次跳闸组件。该组件在汽轮机控制端子板和一个或两个以太网之间提供电气接口。该组件的输出通过连接到相关端子板的DC 62针连接器实现。

IS220PTURH1A采用黑色外壳，带有空气流通开口。这种情况下的前面有多个LED指示灯，以及一个IR(红外端口。)这个端口没有在这个包中使用。在这个外壳内，有一个处理器板、一个专用于涡轮机控制的第二块板和一个模拟采集辅助板。电池组安装在TTURH1C端子板上。处理器板有两个10/100以太网端口、闪存和RAM、一个用于识别的只读芯片、一个内部温度传感器和一个复位电路。

Product description

The IS220PTURH1A is a component developed by GE for its Mark VI system. The Mark VI is one of the final Speedtronic systems released by GE for gas/steam turbine management.

IS220PTURH1A is a single-trip assembly for a steam turbine. This component provides an electrical interface between the turbine control terminal board and one or two Ethernet cables. The output of this component is achieved through a DC 62-pin connector connected to the associated terminal board.

The IS220PTURH1A comes in a black housing with an air outlet. The front of this case has multiple LED indicators, as well as an IR(infrared port). This port is not used in this package. Inside this enclosure, there is a processor board, a second board dedicated to turbine control, and an analog acquisition auxiliary board. The battery string is installed on the TTURH1C terminal board. The processor board has two 10/100 Ethernet ports, flash memory and RAM, a read-only chip for identification, an internal temperature sensor, and a reset circuit.
