1747-KE 罗克韦尔AB 电源控制模块

1747-KE 罗克韦尔AB 电源控制模块

1756-ET是一个以太网/ IP通信模块，属于ControlLogix通信模块的1756系列。该模块是由Allen-Bradley设计的，可作为两个或多个设备（例如控制器和I / O模块）之间的桥梁。

Allen-Bradley 1756-ET以太网/ IP通信模块使用当今已成为开放式工业联网标准的网络协议进行操作，该协议支持实时I / O消息和数据交换。该模块允许用户连接控制I / O和驱动器，并与其他以太网/ IP设备进行通信，充当将消息发送到其他网络上的设备的桥梁，以及充当远程链接上I / O的适配器。


Allen-Bradley 1756-ET以太网/ IP通信模块在5.1伏直流电时的电流消耗为7mA，在24伏直流电时的电流消耗为3 mA。它的功耗为3.7瓦，每小时的散热为12.6 BTU，电压为3伏。

该模块具有一个以太网RJ45类别5端口，并且没有U端口。以太网电缆可以是屏蔽的也可以是非屏蔽的。Allen-Bradley 1756-ET以太网/ IP通信模块具有64个TCP连接和128个CIP连接。这些CIP连接可用于隐式应用程序上的连接的组合。的条件是5至95的相对湿度和至6摄氏度的工作温度。该模块没有外壳，可以位于插槽中。

The 1756-ET is an Ethernet/IP communication module belonging to the 1756 family of ControlLogix communication modules. The module was designed by Allen-Bradley to act as a bridge between two or more devices, such as controllers and I/O modules.

The Allen-Bradley 1756-ET Ethernet/IP communication module operates using a network protocol that has become the standard for open industrial networking today, enabling real-time I/O messaging and data exchange. The module allows users to connect control I/O and drives and communicate with other Ethernet/IP devices, act as a bridge to send messages to devices on other networks, and act as an adapter for I/O on remote links.


The Allen-Bradley 1756-ET Ethernet/IP communication module consumes 7mA at 5.1 volts DC and 3 mA at 24 volts DC. It has a power consumption of 3.7 watts, a heat dissipation of 12.6 BTU per hour and a voltage of 3 volts.

The module has an Ethernet RJ45 category 5 port and no U port. Ethernet cables can be shielded or unshielded. The Allen-Bradley 1756-ET Ethernet/IP communication module has 64 TCP connections and 128 CIP connections. These CIP connections can be used for combinations of connections on implicit applications. The conditions are a relative humidity of 5 to 95 and an operating temperature of 6 degrees Celsius. The module has no shell and can be located in a slot.
