1762-L40BWAR罗克韦尔Allen-Bradley变频器 模块

1762-L40BWAR罗克韦尔Allen-Bradley变频器 模块

The1762-L40BWA是Allen-Bradley 40点控制器模块。该MicroLogix 1200单元具有二十四（24）个输入，兼容24伏直流输入电压，并支持灌入或拉出布线配置。它还具有十六（16）个继电器输出。该控制器支持DIN导轨或面板安装，并使用RSLogix 500编程软件进行编程。

 1762-L40BWA是可编程逻辑控制器（PLC）。该控制器是Allen-Bradley的MicroLogix 1200。它具有总共四十（40）个输入和输出通道，具体包括二十四（24）个离散输入和十四（14）个离散输出。输入通道设计用于通过灌入和拉出布线配置连接承载24VDC的输入设备。输出是触点输出，额定输出为25-125 VDC或120-240 VAC，机械寿命为20,000,000个循环，额定负载为小10A。

该控制器具有集成的8针Mini DIN RS232通信端口，该端口支持DH-485，DF1全双工和半双工，Modbus主站和从站以及ASCII协议。该控制器中的DF1，ASCII和Modbus以对等配置运行。转换器可用于多路复用串行端口，以允许与多个设备进行通信。这些转换器可以是RS232到RS485转换器的RS223到以太网转换器。DH-485非常适合使用外部转换器（例如1761-NET-AIC）连接到网络总线。

由于1762-L40BWA是电子设备，因此需要将该控制器安装到为设备提供足够保护的外壳上。机柜温度必须保持在+ 0°C至+ 55°C的温度下。建议根据安装位置在机箱中安装合适的气候控制设备，例如加热器，风扇或两者的组合。

该控制器使用RSLogix 5000编程软件进行配置，该软件是与Windows XP，Windows 7，Windows Vista，Windows 8和Windows 10操作系统兼容的梯形图编程软件。

The1762-L40BWA is an Allen-Bradley 40-point controller module. The MicroLogix 1200 unit has twenty-four (24) inputs, is compatible with 24 volts DC input voltage, and supports either fill in or pull out wiring configurations. It also has sixteen (16) relay outputs. The controller supports DIN rail or panel mounting and is programmed using RSLogix 500 programming software.

The 1762-L40BWA is a programmable logic controller (PLC). The controller is Allen-Bradley's MicroLogix 1200. It has a total of forty (40) input and output channels, specifically consisting of twenty-four (24) discrete inputs and fourteen (14) discrete outputs. The input channels are designed to connect 24VDC bearing input devices through inlay and pull-out cabling configurations. The output is a contact output rated at 25-125 VDC or 120-240 VAC, with a mechanical life of 20,000,000 cycles and a rated load of less than 10A.

The controller features an integrated 8-pin Mini DIN RS232 communication port that supports DH-485, DF1 full duplex and half duplex, Modbus master and slave, and ASCII protocols. DF1, ASCII and Modbus in this controller run in a peer-to-peer configuration. Converters can be used to multiplex serial ports to allow communication with multiple devices. These converters can be RS232 to RS485 converters and RS223 to Ethernet converters. The DH-485 is ideal for connecting to a network bus using an external converter, such as the 1761-NET-AIC.

Since the 1762-L40BWA is an electronic device, this controller needs to be mounted to a housing that provides adequate protection for the device. The cabinet temperature must be kept at + 0°C to + 55°C. It is recommended to install appropriate climate control devices in the chassis, such as heaters, fans, or a combination of both, depending on the installation location.

The controller is configured using RSLogix 5000 programming software, which is ladder diagram programming software compatible with Windows XP, Windows 7, Windows Vista, Windows 8 and Windows 10 operating systems.
