AB 1769-ADN 美国罗克韦尔PLC模块

AB 1769-ADN 美国罗克韦尔PLC模块

软件系统

DCS的软件体系通常可以为用户提供相当丰富的功能软件模块和功能软件包，控制工程师利用DCS提供的组态软件，将各种功能软件进行适当的“组装连接”(即组态)，生成满足控制系统的要求各种应用软件。
软件系统

现场控制单元的软件主要包括以实时数据库为中心的数据巡检、控制算法、控制输出和网络通信等软件模块组成。

实时数据库起到了中心环节的作用，在这里进行数据共享，各执行代码都与它交换数据，用来存储现场采集的数据、控制输出以及某些计算的中间结果和控制算法结构等方面的信息。

数据巡检模块用以实现现场数据、故障信号的采集，并实现必要的数字滤波、单位变换、补偿运算等辅助功能。DCS的控制功能通过组态生成，不同的系统，需要的控制算法模块各不相同，通常会涉及以下一些模块:算术运算模块、逻辑运算模块、PID控制模块、变型PID模块、手自动切换模块、非线性处理模块、执行器控制模块等等。控制输出模块主要实现控制信号以故障处理的输出.

Software system

DCS software system can usually provide users with quite rich functional software modules and functional software packages, control engineers use the configuration software provided by DCS, the various functional software for appropriate "assembly connection" (that is, configuration), to generate a variety of application software to meet the requirements of the control system.
Software system

The software of the field control unit mainly consists of data inspection, control algorithm, control output and network communication software modules.

The real-time database plays the role of the central link, where the data is shared, and the execution code exchanges data with it, which is used to store the data collected on the spot, the control output, the intermediate results of some calculations and the control algorithm structure and other information.

The data inspection module is used to collect the field data and fault signal, and realize the necessary auxiliary functions such as digital filtering, unit transformation and compensation operation. DCS control function is generated through the configuration, different systems, the need for control algorithm modules are different, usually involves the following modules: arithmetic operation module, logic operation module, PID control module, variant PID module, hand automatic switching module, nonlinear processing module, actuator control module and so on. The control output module mainly realizes the output of control signal to fault processing.
