A-B罗克韦尔 1771-OBD模块 16通道非隔离输出模块 PLC 可编程控制系统

A-B罗克韦尔 1771-OBD模块 16通道非隔离输出模块 PLC 可编程控制系统

Allen-Bradley 1771-OBD是1771产品公告的输出模块。

它有十六（16）个非隔离输出通道，提供标称值为48VDC的10-60VDC输出电压范围。  每个输出电阻的额定电流为2 a，每个模块的额定电流不超过8 a，每个输出导频占空比为0.2 a。

它安装在除1771-A4 I/O机箱外的任何1771-A1B至1771-A4B I/O机箱上。  它使用1771-WH、1771-WHF和1771-WHFB配线臂。

Allen-Bradley 1771-OBD是一个十六（16）通道非隔离输出模块，属于1771产品公告的一部分。

该模块特别适用于PLC5产品系列，通常用于为直流供电的电气负载供电，如指示灯、继电器线圈、螺线管驱动装置和其他装置。

其输出电压范围为10-60 VDC，标称电压输出为48 VDC。

1771-OBD的输出通道额定值为2 A，电阻式，每个模块不超过8 A，每个先导负载输出不超过0.2 A。

Allen-Bradley 1771-OBD is an output module for the 1771 product Bulletin.

It has sixteen (16) non-isolated output channels providing a 10-60VDC output voltage range with a nominal value of 48VDC. The rated current of each output resistor is 2 a, the rated current of each module is not more than 8 a, and the pilot duty cycle of each output is 0.2 a.

It is mounted on any 1771-A1B to 1771-A4B I/O chassis except the 1771-A4 I/O chassis. It uses the 1771-WH, 1771-WHF, and 1771-WHFB wiring arms.

Allen-Bradley 1771-OBD is a sixteen (16) channel non-isolated output module that is part of the 1771 product Bulletin.

This module is particularly suitable for the PLC5 product family and is commonly used to power DC-powered electrical loads such as indicator lights, relay coils, solenoid drives and other devices.

It has an output voltage range of 10-60 VDC and a nominal voltage output of 48 VDC.
