6189-RDT10C是一款10英寸终端，配有Allen Bradley制造的VersaView系列显示器。6189-RDT10C配有彩色图形显示屏和触摸屏。它的触摸屏是一个模拟电阻式屏幕，可以通过手写笔或戴手套或不戴手套的手指来操作。安装6189-RDT10C时，切口的高度应为224毫米，深度应为305毫米。

设备的小间隙应为顶部和底部51毫米，侧面25毫米。需要这些间隙来保持空气流动和通风，以防止外壳周围产生热量。6189-RDT10C周围的环境工作温度应在0至55摄氏度之间。如果温度高于55摄氏度，建议使用冷却风扇降低温度，而如果温度低于0摄氏度，可使用加热器将温度提高到所需水平。

终端只能由受过培训的服务人员根据制造商提供的安装指南进行安装。确保使用适当的安全装置来防止静电放电。打开设备电源之前，确保所有连接都固定到位且连接正确，以防止对系统造成任何损坏。6189-RDT10C高248毫米，宽329毫米，深55毫米，重约2.6千克。6189-RDT10C通过了工业应用认证，是C-UL-美国上市产品，符合CE(EMC，LVD)标准，并且还通过了C-tick认证。

The 6189-RDT10C is a 10-inch terminal with a VersaView series display made by Allen Bradley. The 6189-RDT10C features a color graphic display and touch screen. Its touch screen is an analog resistive screen that can be operated with a stylus or fingers with or without gloves. When installing 6189-RDT10C, the height of the incision should be 224 mm and the depth should be 305 mm.

The minimum clearance of the device should be 51 mm at the top and bottom and 25 mm at the sides. These gaps are needed to maintain air flow and ventilation to prevent heat generation around the enclosure. The ambient operating temperature around 6189-RDT10C should be between 0 and 55 degrees Celsius. If the temperature is above 55 degrees Celsius, it is recommended to use a cooling fan to lower the temperature, while if the temperature is below 0 degrees Celsius, a heater can be used to raise the temperature to the desired level.

The terminal can only be installed by trained service personnel according to the installation guide provided by the manufacturer. Ensure that appropriate safety devices are used to prevent electrostatic discharge. Before powering on the device, ensure that all connections are secured and properly connected to prevent any damage to the system. The 6189-RDT10C is 248 mm high, 329 mm wide, 55 mm deep and weighs about 2.6 kg. 6189-RDT10C has passed the industrial application certification, is C-UL-listed product in the United States, meets the CE(EMC, LVD) standard, and also passed the C-tick certification.
