DS200TCQAG1BHF 燃机卡件GE

DS200TCQAG1BHF 燃机卡件GE

DS200TCQAG1BHF是GE Fanuc自动化制造的连接器式载体I / O。所述IC2CH3 I / O载体重量.113千克并带有用于连接输入/输出电缆36针连接器。

托架提供了用于一个输入/输出模块的背板通信，安装以及现场布线的准备。您可以找到一个模块闩锁孔，以将模块固定到托架上。 该载体还提供连接，可连接多达32个输入/输出点和4个公共电源连接。

在导轨安装过程中，IC2CH3 I / O托架可按以下尺寸卡入DIN导轨：7.5 mm x 35 mm。 为了提供EMC保护，DIN接地。

它们还具有导电和耐腐蚀的表面处理。 借助压接到导线末端的触点，可以直接在连接器类型本身上进行现场接线。

I / O设备可以直接连接到中介I / O端子。 为了安装预接线的连接电缆，请将电缆连接器放置在位于托架上的连接器上，然后向下按压直至闩锁与连接器接合。

The DS200TCQAG1BHF is a connector carrier I/O automatically manufactured by GE Fanuc. The IC2CH3 I/O carrier weighs.113 kg and has a 36-pin connector for connecting input/output cables.

The bracket provides backplane communication, installation, and preparation of field wiring for an input/output module. You can find a module latch latch hole to secure the module to the bracket. The carrier also offers connectivity for up to 32 input/output points and 4 common power connections.

During rail installation, the IC2CH3 I/O bracket can be clambered into the DIN rail in the following dimensions: 7.5 mm x 35 mm. DIN ground to provide EMC protection.

They also have a conductive and corrosion-resistant surface finish. With the help of contacts crimped to the end of the wire, field wiring can be done directly on the connector type itself.

The I/O device can be connected directly to the intermediary I/O terminal. To install the pre-wired connection cable, place the cable connector over the connector located on the carrier, then press down until the latch engages the connector.
