SDCS-AMC-CLAS2 ABB 电子系统 电路板转换器

SDCS-AMC-CLAS2 ABB 电子系统 电路板转换器

SDCS-AMC-CLAS2IGBT系列高频驱动板,主要采用SG3525A作为PWM脉冲形成，输出脉冲频率范围20KHZ一-60KHZ,脉冲间隔互为180度,死区时间可以自行调整。可适用于IGBT全桥逆变串联谐振感应加热装置调频调功。

SDCS-AMC-CLAS2功率范围:10KW-120KW,该控制板接线少,控制集中,没有调试,工作电源电压为三路交流双18V/1A及四个22V/0.5A的电源。

SDCS-AMC-CLAS2具有过流，过压,却水,多种状态指示,并提供开关型霍尔保护接口和线性霍尔保护接口,有全桥逆变IGBT驱动电路,此板可直接组装IGBT高频感应加热装置。

Sdsc-amc-clas2igbt series high frequency driver board, mainly adopts SG3525A as PWM pulse formation, output pulse frequency range 20KHZ -60KHZ, pulse interval 180 degrees each other, dead time can be adjusted by itself. It can be applied to frequency and power regulation of IGBT full-bridge inverter series resonant induction heating device.

Sdsc-amc-clas2 Power range :10KW-120KW, the control board less wiring, centralized control, no debugging, working power supply voltage for three AC double 18V/1A and four 22V/0.5A power supply.

SDCS-AMC-CLAS2 has over current, over voltage, but water, a variety of state indicators, and provides switching type Hall protection interface and linear Hall protection interface, with full bridge inverter IGBT drive circuit, this board can directly assemble IGBT high frequency induction heating device.
