产品描述

GE开发了DS3800NHVD1E1B，以作为高压卡安装在他们的Mark IV系统中。Mark IV是专为燃气/蒸汽轮机控制而设计的系统，可以自动化某些流程以实现一致的管理。这包括关机和冷却等程序。Mark IV还可以监测空气，水和燃料排放。

DS3800NHVD1E1B上的铣削包括朝向电路板顶部的三个椭圆形切口。这些椭圆形的放置使其长尺寸穿过短板尺寸。切口彼此平行。电路板标记为（A 到 L）以进行对齐，并在工厂成对钻孔，围绕电路板边缘（包括每个角）钻孔八次。

该DS3800NHVD1E1B有两个连接器点、三个 LED 和三个变压器，每个变压器都标记为 218A4499P2C1。该板有三个 4 针接头和一个多针连接器（垂直、公头）。

作为高压卡，DS3800NHVD1E1B使用比陶瓷覆盖金属膜更多的碳复合电阻器，但后者仍然出现在板上。CCR 电阻器从带状黄色、紫色、黑色、金色中型电阻器到位于电路板底部的大型 CGN-33 52 Ω 5% 20W Ni 1350W 绕线电阻器不等。这六个电阻器与六个 Sprague 196P104910 电容器交替出现（油中纸）。DS3800NHVD1E1B还使用了其他几个较小的电容器。

该DS3800NHVD1E1B还有一些表面布线，连接标记为该用途的PTH。PTH被标记为“1Wht”或“1Blk”，并用类似颜色的电线连接。

GE DS3800NHVD1E1B 驱动器 电源模块 宝鸡

Product description

GE developed the DS3800NHVD1E1B to be installed as a high voltage card in their Mark IV systems. The Mark IV is a system designed for gas/steam turbine control that automates certain processes for consistent management. This includes procedures such as shutdown and cooling. The Mark IV can also monitor air, water and fuel emissions.

Milling on the DS3800NHVD1E1B consists of three elliptical cuts towards the top of the board. These ovals are placed so that their long dimensions pass through the short plate dimensions. The cuts are parallel to each other. Boards are marked (A to L) for alignment and drilled in pairs at the factory eight times around the edge of the board, including each corner.

The DS3800NHVD1E1B has two connector points, three leds and three transformers, each of which is labeled 218A4499P2C1. The board has three 4-pin connectors and one multi-pin connector (vertical, male).

As a high voltage card, the DS3800NHVD1E1B uses more carbon composite resistors than the ceramic covered metal film, but the latter still appears on the board. CCR resistors range from ribbon yellow, purple, black, gold medium-sized resistors to large CGN-33 52 Ω 5% 20W Ni 1350W wire-wound resistors located at the bottom of the board. These six resistors alternate with six Sprague 196P104910 capacitors (paper in oil). The DS3800NHVD1E1B also uses several other smaller capacitors.

The DS3800NHVD1E1B also has some surface wiring connecting PTH marked for this purpose. PTH is labeled "1Wht" or "1Blk" and connected with similar colored wires.
