产品描述

GE将DS3800NHVD1D1B制造为高压卡，以适应其Mark IV系统。该系统是为燃气轮机或蒸汽轮机管理而创建的，能够自动化某些程序以实现更一致的管理。这包括启动和关闭等过程。Mark IV还能够监测燃料，空气和水的排放。

DS3800NHVD1D1B有从电路板上半部分铣削的椭圆形切口。 每个椭圆的长尺寸平行于DS3800NHVD1D1B的短端。该板还经过工厂钻孔16次，每对两块，并标有对齐标记（A到L）。

该DS3800NHVD1D1B由三个变压器（218A4499 P2 C1），三个红色LED，两个连接器点和四个通信连接器构成。通信连接器分解为一个垂直（公）多针连接器和三个 4 针接头。

由于DS3800NHVD1D1B是高压卡，碳复合电阻器优于陶瓷金属膜，尽管后者中的一些仍然填充电路板。该板有六个 CCR 电阻器，以黄色/紫色/黑色/金色为带状。它还具有六个大型黑色CGN-33 52 Ω 5%20W Ni 1350W电阻器。这些是带有轴向端子的碳复合线绕电阻器。它们位于六张 Sprague 196P 104910 纸的油电容器之间。该板还使用其他较小的电容器，包括 Wesco 8110 100V 电容器。电路板上的所有组件都有标记。

GE DS3800NHVD1D1B 高压卡，以适应其Mark IV系统 咸阳

Product description

GE manufactured the DS3800NHVD1D1B as a high-voltage card to fit its Mark IV system. The system was created for gas turbine or steam turbine management and is capable of automating certain procedures for more consistent management. This includes processes such as startup and shutdown. The Mark IV is also capable of monitoring fuel, air and water emissions.

The DS3800NHVD1D1B has an oval cut milled from the upper half of the board. The long dimensions of each ellipse are parallel to the short end of DS3800NHVD1D1B. The board was also drilled 16 times by the factory, in pairs of two pieces, and marked with alignment marks (A to L).

The DS3800NHVD1D1B consists of three transformers (218A4499 P2C1), three red leds, two connector points and four communication connectors. The communication connector is broken down into a vertical (male) multi-pin connector and three 4-pin connectors.

Since the DS3800NHVD1D1B is a high voltage card, carbon composite resistors are superior to ceramic metal films, although some of the latter are still filled with circuit boards. The board has six CCR resistors in a yellow/purple/black/gold ribbon. It also features six large black CGN-33 52 Ω 5%20W Ni 1350W resistors. These are carbon composite wire-wound resistors with axial terminals. They are located between six Sprague 196P 104910 paper oil capacitors. The board also uses other smaller capacitors, including the Wesco 8110 100V capacitor. All components on the circuit board are marked.
