产品描述

该DS3800NHVD1C1B由GE开发，作为其Mark IV系统的高压卡。该系统用于燃气/蒸汽轮机控制，可以自动化某些过程以实现更一致的管理（冷却、启动、关闭）。它还可以监测空气、燃料和水的排放。

DS3800NHVD1C1B在电路板的上部用椭圆形切口铣削。它们与电路板的短端平行并彼此平行。该板的边缘还有 <> 个工厂钻孔。它被标记为对齐 （A-L.）

DS3800NHVD1C1B有一个连接到电路板的公头垂直多针连接器。它还具有三个 4 针接头。后者都平行于DS3800NHVD1C1B的长边放置。该板还有三个变压器，标记为 218A4499 P2 C1、两个连接器点和三个红色发光二极管 （LED）。

碳复合电阻器（CCR）是DS3800NHVD1C1B上使用的首 选电阻器类型，但也使用了一些陶瓷覆盖的金属膜电阻器。沿着电路板的中间，有六个较小的 CCR（带状黄色、紫色、黑色和金色）。在电路板底部，有六个黑色 CGN-33 52 Ω 5% 20W Ni 1350W CCR 电阻器。中间是六个油纸 Sprague 196P104910 电容器。电路板上还使用其他较小的电容器。所有组件都有标记。

GE DS3800NHVD1C 用于燃气/蒸汽轮机控制 延安

Product description

The DS3800NHVD1C1B was developed by GE as a high voltage card for its Mark IV system. The system is used for gas/steam turbine control and can automate certain processes for more consistent management (cooling, start-up, shutdown). It can also monitor air, fuel and water emissions.

The DS3800NHVD1C1B is milled with an oval cut on the upper part of the board. They are parallel to the short end of the board and parallel to each other. The edge of the board also has a <> factory drill hole. It is labeled aligned (A-L.)

The DS3800NHVD1C1B has a male vertical multi-pin connector connected to the circuit board. It also features three 4-pin joints. The latter are placed parallel to the long side of DS3800NHVD1C1B. The board also has three transformers, labeled 218A4499 P2 C1, two connector points, and three red light emitting diodes (leds).

Carbon composite resistors (CCRS) are the preferred type of resistors used on the DS3800NHVD1C1B, but some ceramic covered metal film resistors are also used. Along the middle of the board, there are six smaller CCRS (ribbon yellow, purple, black, and gold). At the bottom of the board, there are six black CGN-33 52 Ω 5% 20W Ni 1350W CCR resistors. In the middle are six oil-paper Sprague 196P104910 capacitors. Other smaller capacitors are also used on the circuit board. All components are labeled.
