产品描述

DS3800NGRC是GE制造的PCB（印刷电路板），作为其Speedtronic（Mark IV）生产线的一部分。Mark IV专为蒸汽/燃气轮机管理而设计，能够自动化一些程序，如启动和关闭。它还可以防止涡轮机系统在不利或不安全的条件下运行。

该DS3800NGRC设计用作具有以下组件和规格的稳压板：

它是工厂钻孔的，可以安装在各个角落。

它在一条边上标记了对齐（A 到 J）。它标记为 6BA08。

它有四个通信端口，都位于电路板的短边上。 其中包括两个 218A4637-P6 端口（一个右侧和一个左侧）和两个 218A4637-p4 端口（右侧和左侧）。

它有一个沿电路板左边缘连接的六针接头。

它有二十五个集成电路。

它有多个电容器。电容器往往是带有轴向引线的圆形聚酯薄膜通孔电容器。这包括 708A1 m/c 100V 2.0 +/1 10%（黄色）和 708D1 M/e +/- 10%（黄色）。

不同值的电阻填充到电路板上。电阻器既是陶瓷覆盖的金属膜，也是碳复合材料。

GE DS3800NGRC 稳压板 四个通信端口，都位于电路板 安庆

Product description

The DS3800NGRC is a PCB (printed circuit board) manufactured by GE as part of its Speedtronic (Mark IV) line. The Mark IV is designed for steam/gas turbine management and is capable of automating some procedures such as start-up and shutdown. It also prevents turbine systems from operating in adverse or unsafe conditions.

The DS3800NGRC is designed as a pressure stabilizer with the following components and specifications:

It is factory drilled and can be installed in all corners.

It marks the alignment (A to J) on one edge. It's labeled 6BA08.

It has four communication ports, all located on the short sides of the board. These include two 218A4637-P6 ports (one right side and one left side) and two 218A4637-p4 ports (right side and left side).

It has a six-pin connector attached along the left edge of the board.

It has twenty-five integrated circuits.

It has multiple capacitors. Capacitors are usually round mylar through-hole capacitors with axial leads. This includes 708A1 m/c 100V 2.0 +/1 10% (yellow) and 708D1 M/e +/ -10% (yellow).

Different values of resistance fill the circuit board. Resistors are both ceramic covered metal films and carbon composites.
