产品描述

GE的DS3800NGRA1L1E稳压板是Mark IV系列的一个组件。该系列专为蒸汽/燃气轮机管理而设计，可以自动执行一些程序以提高效率（启动/关闭/冷却）。它还通过使用集成芯片组zui大限度地减少由电子故障引起的整个系统的停机时间，这些芯片组在多个板上重复所有重要职责。

DS3800NGRA1L1E具有以下规格：

它的上边缘标记为 A 到 J。

它标记为 2，然后在其左边缘标记为 10 到 80。

它在各个角落都经过工厂钻孔。

它标有代码 6BA04 和 NGRA 6DA04。

它有一个奥加特连接器。这是一个 28 针母连接器

它有四个PCB配套连接器。这些是直角连接器。两个连接器标记为 218A4637P4。两个连接器标记为 218A4637P6。

它主要使用陶瓷覆盖的金属膜电阻器。

它使用聚酯薄膜电容器。电路板上的聚酯薄膜电容器示例包括 .047 +/- 10% M/e AE 80V、708A1 M/e 100V 2.0 +/- 10% 和 708A1 .33 +/- 10% A/e 200V。

它使用陶瓷电容器。

它使用固定真空电容器

该DS3800NGRA1L1E有 25 个电路填充电路板。 这包括能够采用 5.0V 单电源工作的电压比较器、能够产生几纳秒至占空比 100% 之间的输出脉冲的可重新触发一次性、六角逆变器、四通道 SPST CMOS 模拟开关以及设计具有低输入偏置和失调电流的精密运算放大器。

GE DS3800NGRA1L1E 稳压板 有 25 个电路填充电路板 淮南

Product description

GE's DS3800NGRA1L1E pressure stabilizer is a component of the Mark IV series. Designed for steam/gas turbine management, the series automatically performs a number of procedures to increase efficiency (start-up/shutdown/cooling). It also minimizes system-wide downtime caused by electronic failures by using integrated chipsets that repeat all important responsibilities on multiple boards.

The DS3800NGRA1L1E has the following specifications:

Its top edges are labeled A through J.

It is labeled 2 and then 10 to 80 on its left edge.

It goes through factory boreholes at every corner.

It is labeled with the codes 6BA04 and NGRA 6DA04.

It has an Ogat connector. This is a 28 pin female connector

It has four PCB matching connectors. These are right Angle connectors. The two connectors are labeled 218A4637P4. The two connectors are labeled 218A4637P6.

It mainly uses metal film resistors covered with ceramic.

It uses mylar film capacitors. Examples of Mylar capacitors on board include.047 +/ -10% M/e AE 80V, 708A1 M/e 100V 2.0 +/ -10%, and 708A1.33 +/ -10% A/e 200V.

It uses ceramic capacitors.

It uses a fixed vacuum capacitor

The DS3800NGRA1L1E has 25 circuit filled circuit boards. This includes voltage comparators capable of operating with a single 5.0V supply, retrigger throw-offs capable of producing output pulses between a few nanoseconds and 100% duty cycle, hexagonal inverters, four-channel SPST CMOS analog switches, and precision operational amplifiers designed with low input bias and offset currents.
