产品描述

调节板DS3800NGRA1G1B由GE制造，是Mark IV系列的一部分。 该系列是为蒸汽/燃气轮机管理而创建的，通过自动化关闭和启动等程序，可有效提高系统效率。它还可用于监测水、空气和燃料排放。

DS3800NGRA1G1B有一个位于电路板中央的 Augat 连接器。这是一个 28 针母连接器。它还具有四个直角PCB配套连接器（218A4637），两个P4和两个P6，用于与其他板通信。这些连接器位于电路板的两个短边缘。

该DS3800NGRA1G1B有 100 个电路填充电路板。 其中包括三个刚性包络端子。还有模拟开关、六角逆变器、精密放大器、电压比较器和具有清晰互补输出的双路可重新触发一次性。通过应用循环时间短于输出周期时间的输入脉冲序列，可以重新触发到 <>% 占空比。

DS3800NGRA1G1B在工厂钻孔以进行安装。它被标记对齐。大多数元件都有标记，但电路板上的二极管可能没有任何标记。填充电路板的电容器包括陶瓷、固定真空和聚酯薄膜。较大的电容器（80V，100V，200V）通常由聚酯薄膜制成。该板倾向于使用陶瓷覆盖的金属膜电阻器。

GE DS3800NGRA1G1B 调节板 有 100 个电路填充电路板 宿州

Product description

The DS3800NGRA1G1B is manufactured by GE and is part of the Mark IV series. This series has been created for steam/gas turbine management to effectively improve system efficiency by automating procedures such as shutdown and start-up. It can also be used to monitor water, air and fuel emissions.

The DS3800NGRA1G1B has an Augat connector located in the center of the board. This is a 28 pin female connector. It also has four right-angle PCB companion connectors (218A4637), two P4s and two P6s for communication with other boards. These connectors are located on the two short edges of the board.

The DS3800NGRA1G1B has 100 circuits filled with circuit boards. It includes three rigid envelope terminals. There are also analog switches, hexagon inverters, precision amplifiers, voltage comparators, and dual retriggers with clear complementary outputs. By applying an input pulse train with a cycle time shorter than the output cycle time, it is possible to re-trigger to the <>% duty cycle.

The DS3800NGRA1G1B is drilled at the plant for installation. It is labeled aligned. Most components are labeled, but the diodes on the circuit board may not have any labeling. Capacitors filled with circuit boards include ceramic, stationary vacuum and mylar. Larger capacitors (80V, 100V, 200V) are usually made of mylar. The plate tends to use a metal-film resistor covered with ceramic.
