产品描述

DS3800NGPA1B1C是由GE制造的PCB（印刷电路板），作为增益编程卡，适合其Mark IV系列。 该系列专为燃气轮机或蒸汽轮机管理而设计。它可以自动执行一些例程，包括启动和关闭。它还旨在防止系统在不安全或不利条件下运行。

DS3800NGPA1B1C接受可选的辅助板 （DS3800DBPA.） 安装此辅助装置后，主板可以访问其六个电位器和几个 PCB 咬接螺钉安装座。辅助板将安装在主板的右侧，它将放在四个尼龙引脚上，并通过 <> 个板对板连接器固定到位。

DS3800NGPA1B1C标有对齐标记，并标记为“NGPA 6DA08”和“6BA05”。它已经在各个角落钻孔。提取夹安装在右上角。提取器通过为用户提供可选手柄来帮助技术人员进行插入和提取，尤其是在狭小的空间中。它们还可以用作将电路板从插槽中拉出的杠杆。

DS3800NGPA1B1C有一个琥珀色 LED 和六个红色 LED。这些符合十七 （TP） 测试点。该板由五个晶体管、一个电位计和多个集成电路（包括双运算放大器）构成。

多个二极管、电容器和电阻器（主要是陶瓷金属膜）填充DS3800NGPA1B1C。电容器包括一个 25v 50 μf（橙色）电容器。

GE DS3800NGPA1B1C 印刷电路板 接受可选的辅助板 六安

Product description

The DS3800NGPA1B1C is a PCB (printed circuit board) manufactured by GE as a gain programming card for its Mark IV series. The series is designed for gas turbine or steam turbine management. It can automate some routines, including startup and shutdown. It is also designed to prevent the system from operating under unsafe or unfavorable conditions.

DS3800NGPA1B1C Accepts optional auxiliary board (DS3800DBPA.) After installing this auxiliary, the motherboard has access to its six potentiometers and several PCB bite screw mounting mounts. The auxiliary board will be mounted on the right side of the motherboard, which will rest on four nylon pins and be held in place by <> board-to-board connectors.

DS3800NGPA1B1C is marked with alignment markers and labeled "NGPA 6DA08" and "6BA05". It has drilled holes in every corner. The extraction clip is installed in the upper right corner. Extractors help technicians with insertion and extraction by providing users with a removable handle, especially in tight Spaces. They can also be used as levers to pull the board out of its slot.

The DS3800NGPA1B1C has one amber LED and six red leds. These meet seventeen (TP) test points. The board consists of five transistors, a potentiometer, and multiple integrated circuits (including dual operational amplifiers).

Multiple diodes, capacitors and resistors (mainly ceramic metal films) are filled with DS3800NGPA1B1C. The capacitor includes a 25v 50μf (orange) capacitor.
