产品描述

DS3800NGDC是一种印刷电路板，设计为GE的Mark IV系统的组件。Mark IV是为燃气轮机和蒸汽轮机管理而设计的，可以自动化一些程序（启动，关闭，冷却），并且可以保护涡轮机系统并保持其在安全参数范围内运行。该DS3800NGDC设计用作地面探测器板。

DS3800NGDC设计具有以下规格：

它有三个水泥绕线电阻器。其中两个使用尼龙插头将电线抬离电路板。

它有两个（蓝色）25V 100μf电容器和两个黄色Seacor聚酯直流箔和薄膜轴向引线电容器（600v）。 板上还有多个其他电容器。

它在各个角落都经过工厂钻孔。

它有一个边缘沿线的备用 PTH（电镀通孔）。

它有三个晶体管填充电路板，包括一个较大的摩托罗拉晶体管。

它有四个集成电路。

它有六个测试点。但是，它们编号为 TP0 到 TP5。TP0 是一个接地点。

它有一个沿一个边缘的三引脚接头（公头）。

它有一个五位 PC 安装端子条，位于一个边缘，一个 2 位 PCB 接线端子位于另一边缘。

它有两个咬接式 PCB 安装座（螺钉安装座）。

它具有各种电阻器和电容器填充电路板。

GE DS3800NGDC 印刷电路板 可以自动化一些程序 铜陵

Product description

The DS3800NGDC is a printed circuit board designed as a component of GE's Mark IV system. The Mark IV is designed for gas turbine and steam turbine management, automates some procedures (start-up, shutdown, cooling), and can protect turbine systems and keep them operating within safe parameters. The DS3800NGDC is designed to be used as a ground detector board.

The DS3800NGDC is designed with the following specifications:

It has three cement winding resistors. Two of them use nylon plugs to lift the wires off the board.

It has two (blue) 25V 100μf capacitors and two yellow Seacor polyester DC foil and film axial lead capacitors (600v). There are multiple other capacitors on the board.

It goes through factory boreholes at every corner.

It has an edge along the spare PTH (electroplated through hole).

It has three transistor-filled boards, including a larger MOTOROLA transistor.

It has four integrated circuits.

It has six test points. However, they are numbered TP0 through TP5. TP0 is a ground point.

It has a three-pin joint (male head) along one edge.

It has a five-bit PC mounting terminal strip located on one edge and a 2-bit PCB terminal located on the other edge.

It has two bite type PCB mounting seats (screw mounting seats).

It has various resistors and capacitors filled with circuit boards.
