产品描述

该DS3800NFMC1F1E是Speedtronic Mark IV系列的一部分，该系列旨在控制涡轮机。该板由通用电气或GE制造。DS3800NFMC1F1E就是所谓的故障查找器显示电路板。几十年来，Mark IV 系列系统一直用于高效、安全地运行涡轮机。

遮盖DS3800NFMC1F1E左边缘是一个长连接器端口。在电路板的右侧是九 （9） 个 LED，它们在点亮时会发出红色光. LED 也称为发光二极管.十五 （15） 个测试点位于 LED 下方。操作员可以通过使用这些测试点来确保DS3800NFMC1F1C按预期方式工作。DS3800NFMC1F1E周围是三十八（38）个集成电路。每个集成电路上都包含微型电容器、二极管和电阻器。十九 （19） 个晶体管排列在DS3800NFMC1F1E的左侧。

在这些晶体管之间发现了一系列其他组件。电路板上可以看到更多的电容器和二极管，以及各种颜色的电阻器。两个带状电阻器和两个带状电容位于一排其他带状电阻器旁边。字母 A 到 J 印在DS2NFMC3800F1E的上边缘。数字 1 到 <> x <> 标记在连接器端口旁边的左侧。附加的红色实心电阻器、带状电阻器和带状电容位于卡的右侧。

GE DS3800NFMC1F1E 控制涡轮机 长连接器端口 明光
Product description

The DS3800NFMC1F1E is part of the Speedtronic Mark IV series, which is designed to control turbines. The board is manufactured by General Electric or GE. The DS3800NFMC1F1E is the so-called fault finder display board. For decades, Mark IV series systems have been used to operate turbines efficiently and safely.

The left edge of the cover DS3800NFMC1F1E is a long connector port. On the right side of the board are nine (9) leds that glow red when lit. Leds are also called light-emitting diodes. Fifteen (15) test points are located below the LED. Operators can use these test points to ensure that the DS3800NFMC1F1C works as expected. The DS3800NFMC1F1E is surrounded by thirty-eight (38) integrated circuits. Each integrated circuit contains miniature capacitors, diodes and resistors. Nineteen (19) transistors are arranged on the left side of the DS3800NFMC1F1E.

A range of other components were found between these transistors. More capacitors and diodes can be seen on the circuit board, as well as resistors of various colors. Two ribbon resistors and two ribbon capacitors are located next to a row of other ribbon resistors. The letters A to J are printed on the top edge of DS2NFMC3800F1E. The numbers 1 to <> x <> are marked on the left side next to the connector port. Additional red solid resistors, ribbon resistors, and ribbon capacitors are located on the right side of the card.
