产品描述

本产品是Speedtronic Mark IV涡轮控制系列中的一个组件。它由通用电气（GE）制造。DS3800NFMC1F1D是故障查找器显示电路板。几十年来，Mark IV 系列一直被依赖为燃气轮机和蒸汽轮机提供安全性和功能性。

DS3800NFMC1F1D有一个横跨电路板左边缘的长连接器端口。九 （9） 个红色 LED， 也称为发光二极管， 位于电路板的右边缘.LED 下方是十五 （15） 个测试点。这些使用户能够确保电路板正常工作。三十八（38）个集成电路放置在整个DS3800NFMC1F1D。每个集成电路都包含非常小的电阻器、二极管和电容器。位于DS3800NFMC1F1D左侧的是十九 （19） 个晶体管。在晶体管之间是各种其他组件。有不同颜色的带状电阻器以及二极管和电容器。下面是一排带状电阻器，旁边是两 （2） 个带状电阻器和两个带状电容器。沿DS3800NFMC1F1D的上边缘列出的是字母 A 到 J。连接器端口旁边的左边缘是数字 10 到 80 x <>。卡的右侧有更多的带状电阻器、红色实心电阻器和带状电容。

GE DS3800NFMC1F 涡轮控制 显示电路板

Product description

This product is a component of the Speedtronic Mark IV turbine control series. It is manufactured by General Electric. The DS3800NFMC1F1D is the fault finder display board. For decades, the Mark IV series has been relied upon to provide safety and functionality for gas and steam turbines.

The DS3800NFMC1F1D has a long connector port that spans the left edge of the board. Nine (9) red leds, also known as light-emitting diodes, are located on the right edge of the board. Below the LED are fifteen (15) test points. These enable the user to ensure that the board is working properly. Thirty-eight (38) integrated circuits are placed throughout the DS3800NFMC1F1D. Each integrated circuit contains very small resistors, diodes and capacitors. Located to the left of the DS3800NFMC1F1D are nineteen (19) transistors. In between the transistors are various other components. There are different colors of ribbon resistors as well as diodes and capacitors. Below is a row of ribbon resistors, flanked by two (2) ribbon resistors and two ribbon capacitors. Listed along the top edge of DS3800NFMC1F1D are the letters A through J. The left edge next to the connector port is the numbers 10 to 80 x <>. The right side of the card has more ribbon resistors, red solid resistors, and ribbon capacitors.
