通用电气开发了DS3800NFCF1J1G作为Mark IV（Speedtronic）系列的涡轮控制燃烧板。Mark IV是为燃气轮机/蒸汽轮机管理而设计的，可以保护系统免受不安全和不利条件下的运行。它还可以自动执行某些过程，例如启动、关闭和冷却。

DS3800NFCF1J1G充当可选辅助DS3800DFCF的主板。安装此板时，它会添加多个组件，包括电流表。四个尼龙销安装在DS3800NFCF1J1G的左侧，以支撑DS3800DFCF的角落。如果安装了电路板，则 <> 个金属销将电路板锁定到位。

该DS3800NFCF1J1G由 42 个电路组成，包括触发器（经过缓冲以提供与外部干扰的大隔离）、4 位上/下计数器、8 位静态 MOS RAM 芯片和晶体振荡器。所有电路都标有标签。

DS3800NFCF1J1G还包括以下组件：

15 个指示灯。这包括十四个红色和一个琥珀色。

10 针垂直公连接器

两个 218A4637-P4 0027 连接器

两个跳线开关

21个晶体管

29 个 TP 测试点

电阻器，往往由陶瓷覆盖的金属膜制成

不同值的电容器，但包括 8542 +/- M/e 0022 200V 电解电容器

工厂钻孔并标记对齐

两个插水开关。一个标记为“步骤”，另一个标记为“重置”。
