产品描述

IC695CHS016是PACSystem RX3i通用背板，以前由GE Intelligent Platforms（GE IP）制造，现在隶属于艾默生自动化公司。此背板有十二（12）个插槽，支持安装基于PCI的RX3i和90-30系列I/O和选件模块。它有一个双总线背板，仅支持水平安装方向。该背板具有隔离的24VDC输入，3.3 VDC时的额定电流为600 mA，5 VDC时为240 mA。


IC695CHS016是一款十六（16）插槽通用背板，是PACsystem RX3i可编程自动化控制器（PAC）系列的一部分。Emerson Automation的背板用于承载通用控制器和I/O基本模块，并集成支持外围组件互连（PCI）和高速串行总线，从而支持RX3i模块以及传统的90-30系列PLC系列。


IC695CHS016的尺寸为23.7（w）x 5.57（h）x 5.80（d）或601.98（w）×141.5（h）×147.32（d），在3.3 VDC时消耗600 mA，在5 VDC时消耗240 mA，由RX3i电源提供。该底板还支持模块的热插拔，这有助于系统的可用性和维护的方便性。


IC695CHS016背板也可以被一些人员称为机箱、机架或底板。无论使用什么术语，IC695CHS016都为每个模块的背板、配电和主机内部通信提供模块连接。此外，该基板具有用于本地扩展底座互连的必要接口，允许安装额外模块并连接到IC695CHS016托管的同一总线。


IC695CHS016仅支持水平安装。它配有一个接线板，用于隔离24 VDC输入和隔离接地的接线。建议将其固定在额定NEMA/UL 1型外壳或至少额定IP20（IEC60529）外壳的子面板上。必须遵守zui小安装间隙，以允许自然空气冷却。背板各侧所需的zui小安装间隙为102毫米或4英寸。


IC695CHS016背板是一个通用背板，有16个插槽和一个用于隔离输入的接线板。背板由GE Fanuc制造，是RX3i PACSystem系列工业PLC组件的一部分。背板包括一个用于串行扩展的连接器、一个接地点和一个接地棒。背板与来自IC694线路的串行I/O组件、选件模块和基于PCI的IC695组件兼容。IC695CHS016背板需要102毫米（4英寸）的zui小间隙才能获得zui佳性能，而且它是为水平安装而设计的。IC695CHS016通用背板的输入电压为+24伏，在5伏直流电下内部功率为240毫安，而在3.3伏直流电时内部功率为600毫安。当安装在外壳内时，背板的保护等级可以从IP 20到IP 54，具体取决于背板的使用位置。

IC695CHS016 工控设备 GE （16）插槽通用背板

Product description

The IC695CHS016 is a PACSystem RX3i universal backplane formerly manufactured by GE Intelligent Platforms (GE IP), now part of Emerson Automation. This backplane has twelve (12) slots and supports the installation of PCI-based RX3i and 90-30 series I/O and option modules. It has a dual bus backplane that supports only horizontal mounting directions. The backplane has an isolated 24VDC input and is rated at 600 mA at 3.3 VDC and 240 mA at 5 VDC.


The IC695CHS016 is a sixteen (16) slot universal backplane that is part of the PACsystem RX3i Programmable Automation Controller (PAC) family. Emerson Automation's backplane is used to host the universal controller and I/O base modules and integrates support for Peripheral component Interconnect (PCI) and high-speed serial buses to support RX3i modules as well as the traditional 90-30 series PLC family.


The IC695CHS016 has dimensions of 23.7 (w) x 5.57 (h) x 5.80 (d) or 601.98 (w) x 141.5 (h) x 147.32 (d), consumes 600 mA at 3.3 VDC and 240 mA at 5 VDC, and is supplied by an RX3i power supply. The backboard also supports hot-swappable modules, which contributes to the availability and ease of maintenance of the system.


The IC695CHS016 backplane may also be referred to by some as a chassis, rack, or baseboard. Regardless of the terminology used, the IC695CHS016 provides module connectivity for each module's backplane, power distribution, and host internal communication. In addition, the substrate has the necessary interfaces for local expansion dock interconnections, allowing additional modules to be installed and connected to the same bus hosted by the IC695CHS016.


The IC695CHS016 supports horizontal installation only. It comes with a patch panel for isolating the 24 VDC input and isolating the grounding of the wiring. It is recommended that it be fixed to a subpanel of a rated NEMA/UL Type 1 housing or at least rated IP20 (IEC60529) housing. Minimum installation gaps must be observed to allow natural air cooling. The minimum mounting clearance required on each side of the backplane is 102 mm or 4 inches.


The IC695CHS016 backplane is a universal backplane with 16 slots and a patch board for isolating inputs. The backplane is manufactured by GE Fanuc and is part of the RX3i PACSystem series of industrial PLC components. The backplane includes a connector for serial expansion, a ground point, and a ground rod. The backplane is compatible with serial I/O components from the IC694 line, option modules, and PCI-based IC695 components. The IC695CHS016 backplane requires a minimum clearance of 102 mm (4 inches) for optimal performance, and it is designed for horizontal mounting. The IC695CHS016 universal backplane has an input voltage of +24 volts and an internal power of 240 mA at 5 volts DC and 600 mA at 3.3 volts DC. When installed in the housing, the backplane's protection level can range from IP 20 to IP 54, depending on where the backplane is used.
