产品描述



GE背板控制板型号IS200EBKPG1C来自EX2100系列；板的上部具有用于插入式控制板的DIN连接器，并且板的底部也具有用于适当功能的圆形DIN连接器和D-SUB连接器。



IS200EBKPG1C型号是通用电气公司生产的励磁控制器系列的一部分。该型号是连接EX2100系列其余板/控制器的板。IS200EBKPG1C是IS200EBKPG控制板组的第三个也是zui后一个型号。



IS200EBKPG1C型号中有三个部分，这些部分有不同的板可以连接到相应的部分，例如，在部分C中，唯 一可以连接的板是EISB、EMIO和DSPX。C部分中的接头为J314、J315、J414、J415、J514和J515。J315、J415、J514和J515连接器也有特定的连接，J315将连接到EPCT板，J415将连接至ECTB板，J514将连接至其中一个EACF板，J515将连接一个EXTB板。每个板都有特定的功能，并且都是输入/输出端子板。

IS200EBKPG1C 背板控制板 EX2100系列

Product description



GE backplane control panel model IS200EBKPG1C from the EX2100 series; The upper part of the board has DIN connectors for plug-in control boards, and the bottom part of the board also has circular DIN connectors and D-SUB connectors for appropriate functions.



The IS200EBKPG1C model is part of a family of excitation controllers produced by General Electric Company. This model is the board that connects to the rest of the EX2100 series boards/controllers. The IS200EBKPG1C is the third and final model of the IS200EBKPG panel.



There are three sections in the IS200EBKPG1C model, which have different boards that can be connected to the corresponding sections, for example, in Part C, the only boards that can be connected are EISB, EMIO, and DSPX. The joints in Part C are J314, J315, J414, J415, J514, and J515. The J315, J415, J514, and J515 connectors also have specific connections, J315 will be connected to the EPCT board, J415 will be connected to the ECTB board, J514 will be connected to one of the EACF boards, and J515 will be connected to an EXTB board. Each board has a specific function and is an input/output terminal board.
