IS200EDCFG1B 是一种EDCF型号 I/O端子板

IS200EDCFG1B 是一种EDCF型号 I/O端子板

产品描述



EX2100型号IS200EDCFG1B是一种EDCF型号，是一种I/O端子板，通过七个选择器设置来测量场电压，以缩小电桥的比例，这一过程具体取决于电桥的应用类型。



励磁机直流反馈板IS200EDCFG1B是美国通用电气公司生产的励磁控制器系列的一部分。该型号连接到提供输出反馈的直流分流器。IS200EDCFG1B板是高压接口系统的一部分。该型号也是I/O端子板的一部分，该端子板主要控制直流输出和反馈以及电流电压。



EDCF型号的场电压反馈电路在选择器上总共提供了七个设置，这些设置会降低电桥电压，但这完全取决于电桥的设置应用。连接到IS200EDCFG1B型号的光纤电缆在EISB板和EDCF板之间提供隔离电压，并具有高抗噪性。



来自IS200EDCFG1B型号的励磁电流反馈通过位于SCR桥的直流分流器进行测量。当励磁电流正常运行时，它将产生一个低电平信号，zui大值为500 MV，这将是另一个放大器的输入。

IS200EDCFG1B 是一种EDCF型号 I/O端子板

Product description



The EX2100 model IS200EDCFG1B, an EDCF model, is an I/O terminal board that measures the field voltage through seven selector Settings to reduce the scale of the bridge, a process that depends on the type of application of the bridge.



The exciter DC feedback board IS200EDCFG1B is part of the exciter controller family produced by General Electric Company. This model is connected to a DC shunt that provides output feedback. The IS200EDCFG1B board is part of the high voltage interface system. This model is also part of the I/O terminal board, which primarily controls DC output and feedback as well as current voltage.



The EDCF model field voltage feedback circuit provides a total of seven Settings on the selector that reduce the bridge voltage, but this depends entirely on the bridge setting application. The fiber optic cable connected to the IS200EDCFG1B model provides isolation voltage between the EISB board and the EDCF board and has high noise resistance.



The excitation current feedback from the IS200EDCFG1B model is measured via a DC shunt located on the SCR bridge. When the excitation current is operating normally, it will produce a low level signal with a maximum of 500 MV, which will be the input to another amplifier.

IS200EDCFG1B 是一种EDCF型号 I/O端子板
