IS200EISBH1A 是激励器ISBus板

IS200EISBH1A  是激励器ISBus板

产品描述

IS200EISBH1A型号是激励器ISBus板，是通用电气生产的EX2100系列的一部分。该板是一种特殊的通信接口板，与 C、M1 和 M2 控制模块配合使用。该模块的另一个功能是通过背板连接器发送和接收光纤信号。前面板上有六个光纤连接器，面板上的发生器场接受电流和电压。

IS200EISBH1A板将它通过背板控制器收到的反馈传输到DSPX控制器，它还将使用RS-232C和DSPX模块在工具和键盘端口之间进行通信。该模块通常将管理整个机柜中的所有光纤通信。从物理上讲，EISB 模块是一个 3U 高的模块，也是一个单插槽。第 IS200EISBH1A 部分还将信号传输到地面检测模块 （EGDM）。

IS200EISBH1A  是激励器ISBus板

Product description

The IS200EISBH1A model is an exciter ISBus board that is part of the EX2100 series produced by General Electric. The board is a special communication interface board used with C, M1 and M2 control modules. Another function of the module is to send and receive fiber optic signals through the backplane connector. There are six fiber optic connectors on the front panel, and a generator field on the panel accepts current and voltage.

The IS200EISBH1A board transmits the feedback it receives through the backplane controller to the DSPX controller, and it will also use the RS-232C and DSPX modules to communicate between tools and keyboard ports. This module will typically manage all fiber optic communications throughout the cabinet. Physically, the EISB module is a 3U high module and also a single slot. Part IS200EISBH1A also transmits the signal to the Ground Detection Module (EGDM).

IS200EISBH1A  是激励器ISBus板
