1732ES-IB16 端口以太网/IP 模块

1732ES-IB16 端口以太网/IP 模块

Allen-Bradley 1732ES-IB16 2 端口以太网/IP 模块具有 16 个输出和 24 伏源输出类型。该模块的zui大导通状态输出电压降额定值为 0.5 V，zui小非峰值阻断电压额定值为 30 V。zui大导通状态输出电压为 30 V，zui大传感器源电压为 30 V。该模块的zui大导通状态输出电流为 2 安培，每个模块的zui大电流为所有输出为 8 安培。它的飞行员职责等级为DC-14。

Allen-Bradley 的 1732ES-IB16模块的一些一般规格包括 30 伏的zui大辅助电源电压额定值和 12 伏的zui低额定值。每个输入的zui大传感器源电流为 50 毫安。ArmorBlock 1732ES-IB16模块包含的功能是 LED 指示灯，允许zui终用户确定模块的状态，模块状态指示灯为红色/绿色，网络状态 LED 为红色/绿色，链路状态 LED 为绿色，辅助电源 LED 为绿色，I/O LED 为黄色。


该模块的环境规格包括 -4 到 140 华氏度的工作温度范围和 -40 到 185 华氏度的存储温度。周围zui高温度不应超过 140 华氏度。该模块的相对湿度范围应保持在 5% 到 95% 之间（非冷凝）。1732ES-IB16 模块的更多环境规格包括 1 组、A 类排放等级和 5 至 10 赫兹时 500 g 的振动等级。该模块的尺寸为 179 x 65 x 43.25 毫米，或 7.05 x 2.56 x 1.70 英寸。它重约 0.34 公斤，或 0.75 磅。

1732ES-IB16 端口以太网/IP 模块

The Allen-Bradley 1732ES-IB16 2-port Ethernet /IP module has 16 outputs and 24 volt source output types. The module has a maximum on-state output voltage drop rating of 0.5 V and a minimum off-peak blocking voltage rating of 30 V. The maximum on-state output voltage is 30 V and the maximum sensor source voltage is 30 V. The maximum on-state output current for this module is 2 amps, and the maximum current for each module is 8 amps for all outputs. Her pilot duty class is DC-14.

Some general specifications for Allen-Bradley's 1732ES-IB16 module include a maximum auxiliary supply voltage rating of 30 volts and a minimum rating of 12 volts. The maximum sensor source current per input is 50 MA. The function included in the ArmorBlock 1732ES-IB16 module is the LED indicator that allows the end user to determine the status of the module, the module status indicator is red/green, the network status LED is red/green, the link status LED is green, the auxiliary power LED is green, and the module status indicator is red/green. The I/O LED is yellow.


The module's environmental specifications include an operating temperature range of -4 to 140 degrees Fahrenheit and a storage temperature of -40 to 185 degrees Fahrenheit. The maximum surrounding temperature should not exceed 140 degrees Fahrenheit. The relative humidity range of the module should be maintained between 5% and 95% (non-condensing). Additional environmental specifications for the 1732ES-IB16 module include A Group 1, Class A emission rating and a vibration rating of 500 g at 5 to 10 Hz. The module measures 179 x 65 x 43.25 mm, or 7.05 x 2.56 x 1.70 inches. It weighs about 0.34 kilograms, or 0.75 pounds.

1732ES-IB16 端口以太网/IP 模块
