Allen-Bradley 1734-IR2 是一款点 I/O 电阻温度检测器 （RTD） 和电阻输入模块。该模块非常适合温度应用或安装了传感器的应用，这些传感器提供电阻信号作为反馈变量。

1734-IR@ 是 POINT I/O 系列的一部分，是一款经济高效、节省面板空间的模块，因为它支持安装到标准的 35mm DIN 导轨上，占用空间仅为 56 x 12 x 75.5 mm（2.21 x 0.47 x 2.97 英寸）。此外，它具有开放式外壳，这意味着任何适合应用领域的外壳都同样适用于 1734-IR2。

1734-IR2 主要具有两 （2） 个电阻温度检测器 （RTD） 输入通道。每个输入通道都兼容与RTD传感器的直接接口，例如100 Pt α = 0.00385;200 Pt α = 0.00385;100 Pt α = 0.003916;200 Pt α = 0.003916;10 Cu α = 0.00427;100 Ni α = 0.00618;120 Ni α = 0.00618 和 120 Ni α = 0.00672 传感器和 0-600 Ω电阻信号的直接接线。该模块是一个 16 尼特分辨率模拟输入模块，非常适合温度应用。它需要使用 1734-TB、1734-TBS、1734-TOP 或 1734-TOPS 接线底座组件。

1734-IR2 具有内置的三角积分模数转换器，分辨率具体为 16 位，9.5 mΩ/cnt 0.03 °C/cnt （Pt385 @ 25 °C） [0.05 °F/cnt （Pt385 @ 77 °F）。转换后的数据存储为有符号整数。它的绝 对精度为 0.1% 满量程 @ 25 °C （77 °F）。该模块经过工厂校准。

1734-IR2尺寸为2.21 x 0.47 x.2.97英寸，重量为0.036千克或0.08磅，并具有开放式外壳。它可以使用DIN导轨进行安装，并且与1734-TB，1734-TBS，1734-***734-TOPS终端底座兼容。该模块的分辨率为 16 位，9.5 毫欧/cnt 和 0.03 摄氏度/cnt。它还具有增量西格玛转换类型和有符号整数数据格式。操作员可以从四个预定义的刻度中选择模块的温度数据格式：摄氏度、华氏度、开尔文和朗金，以及一个自定义刻度 （mV）。

1734-IR2 模块还具有警报功能，可提醒用户注意欠量程、超量程、开路以及低电平或高电平条件。1734-IR2 没有zui大过载输入保护，也不需要外部直流电源即可运行。1734-IR2 的输入为 15 mA 0 至 10 伏和 +/-10 伏，而其标称输入为 24 伏直流电。它的输入范围为 0 至 600 欧姆，在 220 伏直流电时的zui大 POINTbus 电流为 5 mA。模块的zui大功耗为1瓦，zui大热耗散为3.3 BTU/小时。它还具有 5 至 95 的非冷凝相对湿度、-20 至 55 摄氏度的工作温度范围和 -40 至 85 摄氏度的存储温度范围。1734-IR2 的工作冲击额定值为 30 g，非工作冲击额定值为 50 g，5 至 10 赫兹时的工作振动为 500 g。1734-IR2 还具有从 I/O 到系统的 50 V 连续隔离电压。

1734-IR2 是一款点 I/O 电阻温度检测器

Allen-Bradley 1734-IR2 is a point I/O resistance temperature detector (RTD) and resistance input module. The module is ideal for temperature applications or applications where sensors are installed that provide a resistance signal as a feedback variable.

The 1734-IR@ is part of the POINT I/O family and is a cost-effective, panel space-saving module, as it supports mounting onto a standard 35mm DIN rail and occupies only 56 x 12 x 75.5 mm (2.21 x 0.47 x 2.97 inches). In addition, it has an open housing, which means that any housing suitable for the application field is equally suitable for the 1734-IR2.

The 1734-IR2 primarily has two (2) resistance temperature detector (RTD) input channels. Each input channel is compatible with a direct interface to the RTD sensor, e.g. 100 pt-α = 0.00385; 200 pt-α = 0.00385; 100 pt-α = 0.003916; 200 pt-α = 0.003916; 10 Cuα = 0.00427; 100 Niα = 0.00618; 120 Niα = 0.00618 and 120 Niα = 0.00672 Direct wiring of sensors and 0-600Ω resistance signals. The module is a 16 nit resolution analog input module, ideal for temperature applications. It requires the use of 1734-TB, 1734-TBS, 1734-TOP, or 1734-TOPS wiring base assemblies.

The 1734-IR2 has a built-in trigonometry integrated analog-to-digital converter with a resolution of 16 bits, 9.5mΩ /cnt 0.03 °C/cnt (Pt385@25 °C) [0.05 °F/cnt (Pt385@77 °F). The converted data is stored as signed integers. Its absolute accuracy is 0.1% full scale @ 25 °C (77 °F). The module is factory calibrated.

The 1734-IR2 measures 2.21 x 0.47 x.2.97 inches, weighs 0.036 kg or 0.08 pounds, and has an open housing. It can be mounted using DIN rails and is compatible with 1734-TB, 1734-TBS, 1734-TOP or 1734-TOPS terminal mounts. The module has a resolution of 16 bits, 9.5 milliohm /cnt and 0.03 degrees Celsius /cnt. It also has an incremental Sigma conversion type and a signed integer data format. The operator can select the module's temperature data format from four predefined scales: Celsius, Fahrenheit, Kelvin, and Rankine, as well as a custom scale (mV).

The 1734-IR2 module also has an alarm function to alert the user to underrange, overrange, open circuit, and low or high level conditions. The 1734-IR2 has no maximum overload input protection and does not require external DC power to operate. The 1734-IR2 has inputs of 15 mA 0 to 10 volts and +/-10 volts, while its nominal input is 24 volts DC. It has an input range of 0 to 600 ohms and a maximum POINTbus current of 5 mA at 220 volts DC. The maximum power consumption of the module is 1 watt and the maximum heat dissipation is 3.3 BTU/ hour. It also has a non-condensing relative humidity of 5 to 95 degrees, an operating temperature range of -20 to 55 degrees Celsius, and a storage temperature range of -40 to 85 degrees Celsius. The 1734-IR2 has an operating shock rating of 30 g, a non-operating shock rating of 50 g, and an operating vibration of 500 g at 5 to 10 Hz. The 1734-IR2 also features 50 V continuous isolation voltage from I/O to the system.
