Allen Bradley 1747-L511是SLC 5/01处理器

Allen Bradley 1747-L511是SLC 5/01处理器

Allen Bradley 1747-L511是SLC 5/01处理器，也是SLC 500系统的一部分。它是一种小型、易于使用的处理器，具有广泛的应用，包括小型过程控制、物料搬运、HVAC 控制等。它包含一个基于 PLC-5 处理器的高 级指令集，可以独立使用，也可以分布在整个 SCADA 应用中。

1747-L511 处理器的用户总内存为 1 K。它具有多达 960 个本地数字 I/O;每个关键字的程序扫描时间为 8 毫秒，I/O 扫描时间为 2.6 毫秒。背板电流在 350 伏直流时为 5 mA，在 105 伏直流时为 24 mA，它在本地 I/O 机箱中zui多具有 3 个本地 I/O 机箱，zui多有 30 个模块 I/O 插槽。对于通信，它使用只能发送或接收消息但无法启动消息的DH-485。

此模块与 1746-BLM、1746-BTM、1746-MPM、1746-HS、1746-HSCE、1746-QV、1747-SN、1747-SDN 或 1747-SCNR15 模块不兼容。它适用于清洁干燥的工业环境，工作温度为 0-60 摄氏度，工作冲击为 30 g。它具有用于 1747-L514 模块的备用电池和用于 1747-L511 模块的电容器备份，并包括红色 PC 运行、CPU 故障、强制 I/O 和电池电量低、用于故障排除和诊断的 LED 状态指示灯。

1747-L511 是 SLC 500 模块化硬件的入门级处理器。该处理器具有zui基本的功能，具有1KB内存，使其能够处理多达3940个IO信号。但是，此模块不支持远程 I/O 拓扑的实现。它zui多只能扩展三 （3） 个任何类型的 SLC 机箱或zui多 30 个 IO 插槽。该处理器符合美国和加拿大安全标准 UL 认证，符合 CE 标准，并带有 C-Tick 标志。

该处理器具有电可擦除可编程只读存储器（EEPROM）的存储器备份选项，该存储器基本上是非易失性存储器，该非易失性存储器可用于高 级存储可编程逻辑控制器（PLC）程序，以防止意外删除通常由电涌和电池耗尽引起的。还可以将其配置为在每次启动电源循环时自动加载用户程序。

该处理器的集成存储器是随机存取存储器（RAM），由锂电池维护，可持续使用长达两（2）年。电池电量由电池电量低 LED 灯指示，当电池电压低时激活。此电池可更换为 1747-BA，但不要在断开电源后更换电池。更换处理器时必须主动供电，否则用户程序将被删除。

除电池指示灯外，此处理器还安装了其他 LED 状态指示灯。这些指示器包括运行、CPU 故障和强制 I/O。

Allen Bradley 1747-L511是SLC 5/01处理器


The Allen Bradley 1747-L511 is an SLC 5/01 processor and part of the SLC 500 system. It is a small, easy to use processor with a wide range of applications including small process control, material handling, HVAC control and more. It contains an advanced instruction set based on the PLC-5 processor and can be used independently or distributed throughout the SCADA application.

The 1747-L511 processor has a total user memory of 1 K. It has up to 960 local digital I/ OS; The program scan time for each keyword is 8 milliseconds and the I/O scan time is 2.6 milliseconds. The backplane current is 5 mA at 350 volts DC and 24 mA at 105 volts DC, and it has up to 3 local I/O enclosures in the local I/O chassis with up to 30 module I/O slots. For communication, it uses DH-485, which can only send or receive messages but cannot start them.

This module is not compatible with the 1746-BLM, 1746-BTM, 1746-MPM, 1746-HS, 1746-HSCE, 1746-QV, 1747-SN, 1747-SDN, or 1747-SCNR15 modules. It is suitable for clean and dry industrial environment, the operating temperature is 0-60 degrees Celsius, and the working impact is 30 g. It has a backup battery for the 1747-L514 module and a capacitor backup for the 1747-L511 module, and includes a red PC run, CPU failure, forced I/O and low battery, LED status indicator for troubleshooting and diagnosis.

The 1747-L511 is the entry-level processor for the SLC 500 modular hardware. The processor has the most basic features, with 1KB of memory, enabling it to process up to 3940 IO signals. However, this module does not support the implementation of remote I/O topologies. It can only expand up to three (3) SLC enclosures of any type or up to 30 IO slots. The processor meets the UL certification of the US and Canadian safety standards, meets the CE standard, and carries the C-Tick mark.

The processor has a memory backup option for electrically erasable programmable read-only memory (EEPROM), which is essentially non-volatile memory that can be used to permanently store programmable logic controller (PLC) programs to prevent accidental erasure usually caused by power surges and battery depletion. It can also be configured to automatically load user programs each time a power cycle is started.

The processor's integrated memory is random access memory (RAM), which is maintained by a lithium battery and can last up to two (2) years. The battery level is indicated by the low battery LED light and activated when the battery is low. This battery can be replaced with 1747-BA, but do not replace the battery after disconnecting the power supply. The power supply must be active when replacing the processor, otherwise the user program will be deleted.

In addition to the battery indicator, this processor is equipped with other LED status indicators. These indicators include running, CPU failure, and forced I/O.
