1756-M08SE 支持集成多达八 （8） 个 Kinetix 驱动器

1756-M08SE 支持集成多达八 （8） 个 Kinetix 驱动器

Allen-Bradley 1756-M08SE是一个ControlLogix模块。它是一个串行实时通信系统（SERCOS）接口模块，用于使ControlLogix机架直接与SERCOS驱动器连接。

1756-M08SE 支持集成多达八 （8） 个 Kinetix 驱动器，兼容不同 Kinetix 系列的各种驱动器，例如 2093 Kinetix 2000 多轴伺服驱动器、2094 Kinetix 6000 多轴伺服驱动器、2099 Kinetix 7000 大功率伺服驱动器和 2098 Ultra3000 SERCOS 伺服驱动器。1756-M08SE 能够以 4 Mbps 和 8 Mbps 的速度和周期时间执行数据交换，具体取决于数据速率和连接的驱动器数量。在 4 Mbps 数据速率下，周期时间包括 0.5 ms，zui多 2 个驱动器;1 ms，zui多 4 个驱动器和 2 ms，zui多 8 个驱动器，而在 8 Mbps 时，周期时间为 0.5 ms，zui多 4 个驱动器;1 毫秒，zui多 8 个驱动器，2 毫秒，zui多 16 个驱动器。此 SERCOS 可以配置为实现不同的驱动控制模式，例如位置、速度和扭矩。

1756-M08SE 直接安装在 1756 ControlLogix 机箱上。兼容的机箱分别为 1756-A4、1756-A7、1756-A10、1756-A13、1756-A17 以及标准和冗余电源，例如 1756-PA72/C、1756-PA75/B、1756-PB72/C、1756-PB75/B、1756-PC75/B、1756-PH75/B 和 1756-PA75R、1756-PB75R、1756-PSCA2。

用于SERCOS驱动器高速通信的兼容物理介质是塑料光纤电缆，目录号为2090-SCEPxx-0无护套，氯化聚乙烯2090-SCVPxx-0标准护套，聚氯乙烯2090-SCNPxx-0尼龙护套和2090-SCVGxx-0标准护套，聚氯乙烯玻璃光缆。

1756-M08SE 支持集成多达八 （8） 个 Kinetix 驱动器

Allen-Bradley 1756-M08SE is a ControlLogix module. It is a Serial Real-time Communication System (SERCOS) interface module that enables the ControlLogix rack to connect directly to SERCOS drives.

The 1756-M08SE supports the integration of up to eight (8) Kinetix drives, compatible with various drives in different Kinetix series, Examples include 2093 Kinetix 2000 multi-axis servo drive, 2094 Kinetix 6000 multi-axis servo drive, 2099 Kinetix 7000 High power servo drive and 2098 Ultra3000 SERCOS servo drive. The 1756-M08SE is capable of performing data exchange at speeds of 4 Mbps and 8 Mbps and cycle times, depending on the data rate and number of connected drives. At 4 Mbps data rate, cycle time includes 0.5 ms, up to 2 drives; 1 ms, up to 4 drives and 2 ms, up to 8 drives, while at 8 Mbps, the cycle time is 0.5 ms, up to 4 drives; 1 ms, up to 8 drives, 2 ms, up to 16 drives. This SERCOS can be configured to implement different drive control modes, such as position, speed, and torque.

The 1756-M08SE is installed directly in the 1756 ControlLogix chassis. Compatible chassis are 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 as well as standard and redundant power supplies, Examples include 1756-PA72/C, 1756-PA75/B, 1756-PB72/C, 1756-PB75/B, 1756-PC75/B, 1756-PH75/B, and 1756-PA75R, 1756-PB75R, 1756-PSCA2.

Compatible physical media for high speed communication with SERCOS drivers are plastic fiber optic cables, catalog number 2090-SCEPxx-0 without sheath, chlorinated polyethylene 2090-SCVPxx-0 standard sheath, polyvinyl chloride 2090-SCNPxx-0 nylon sheath and 2090-SCVGxx-0 standard sheath, Polyvinyl chloride glass optical cable.

Allen-Bradley 1756-M08SE is a ControlLogix module. It is a Serial Real-time Communication System (SERCOS) interface module that enables the ControlLogix rack to connect directly to SERCOS drives.

The 1756-M08SE supports the integration of up to eight (8) Kinetix drives, compatible with various drives in different Kinetix series, Examples include 2093 Kinetix 2000 multi-axis servo drive, 2094 Kinetix 6000 multi-axis servo drive, 2099 Kinetix 7000 High power servo drive and 2098 Ultra3000 SERCOS servo drive. The 1756-M08SE is capable of performing data exchange at speeds of 4 Mbps and 8 Mbps and cycle times, depending on the data rate and number of connected drives. At 4 Mbps data rate, cycle time includes 0.5 ms, up to 2 drives; 1 ms, up to 4 drives and 2 ms, up to 8 drives, while at 8 Mbps, the cycle time is 0.5 ms, up to 4 drives; 1 ms, up to 8 drives, 2 ms, up to 16 drives. This SERCOS can be configured to implement different drive control modes, such as position, speed, and torque.

The 1756-M08SE is installed directly in the 1756 ControlLogix chassis. Compatible chassis are 1756-A4, 1756-A7, 1756-A10, 1756-A13, 1756-A17 as well as standard and redundant power supplies, Examples include 1756-PA72/C, 1756-PA75/B, 1756-PB72/C, 1756-PB75/B, 1756-PC75/B, 1756-PH75/B, and 1756-PA75R, 1756-PB75R, 1756-PSCA2.

Compatible physical media for high speed communication with SERCOS drivers are plastic fiber optic cables, catalog number 2090-SCEPxx-0 without sheath, chlorinated polyethylene 2090-SCVPxx-0 standard sheath, polyvinyl chloride 2090-SCNPxx-0 nylon sheath and 2090-SCVGxx-0 standard sheath, Polyvinyl chloride glass optical cable.

1756-M08SE 支持集成多达八 （8） 个 Kinetix 驱动器
