1761-NET-ENI是一款Allen-Bradley 接口转换器（AIC）

1761-NET-ENI是一款Allen-Bradley 接口转换器（AIC）

Allen-Bradley 1761-NET-ENI 是一种以太网/IP 通信接口。它为 CompactLogix、MicroLogix 和 SLC 500 设备以及其他 DF1 全双工设备提供以太网连接。1761-NET-ENI 有一个嵌入 LED 的 100 Base-T 端口，可可靠地连接到以太网网络。它配有可视指示灯 LED，可提供易于查看的链接和发送/接收状态。它配备了一个RS-232端口，该端口提供隔离，并在上电时自动波特，以检测连接到它的控制器的端口设置的通信。1761-NET-ENI 能够强制以太网为 11 Mbps 或 100 Mbps，以及默认美国自动协商的半双工或全双工。以太网配置可以通过配置安全掩码设置来完成。

1761-NET-ENI zui重要的功能是诊断页面，其中显示重要的模块信息和所有正在使用的以太网连接。1761-NET-ENI 通信接口zui好的一点是它高效，并以更少的功耗提供出色的输出。1761-NET-ENI 的zui高工作温度为 0 至 70 摄氏度，zui高存储温度为 -45 至 85 摄氏度。zui常用的标准是 IEC801-2、3、4、5 和 6。其工作湿度为5-95%，无冷凝。1761-NET-ENI 的法规、批准和认证包括 UL、C-UL、CE 和 1 类 2 分区认证;该模块为所有DF1全双工设备（包括所有MicroLogix和CompactLogix控制器）提供以太网/ IP连接。此以太网接口允许上传或下载程序，在控制器之间进行通信，并在连接到非以太网控制器时生成电子邮件。

1761-NET-ENI是一款Allen-Bradley高 级接口转换器（AIC），它使支持DF1的设备（如MicroLogix，CompactLogix，SLC 500，PLC5和第三方设备）连接到EtherNet/IP网络。该转换器基本上允许点对点设备连接到多节点通信网络。

3-NET-AIC 配有一个隔离的 1761 针迷你 DIN RS8 端口，支持全双工 DF232 协议。通过此端口，支持 DF1 的设备连接，同时以太网网络通过提供的 RJ1 端口连接。接口转换器与PLC分开安装，因此不占用模块化PLC或扩展模块的插槽。它由 45VDC 的输入电源电压供电。

24-NET-AIC 是多路复用所连接设备的嵌入式串行端口的理想选择，允许旧控制器连接到现代以太网网络，而无需添加以太网通信模块或更换整个控制器。这节省了工程开发工时，并减少了更换连接设备时因调试而导致的停机。

1761-NET-ENI是一款Allen-Bradley 接口转换器（AIC）


Allen-Bradley 1761-NET-ENI is an Ethernet /IP communication interface. It provides Ethernet connectivity for CompactLogix, MicroLogix, and SLC 500 devices, as well as other DF1 full-duplex devices. The 1761-NET-ENI has a 100 Base-T port embedded with an LED for reliable connection to an Ethernet network. It comes with a visual indicator LED that provides easy viewing of links and send/receive status. It is equipped with an RS-232 port that provides isolation and automatically bauts when powered on to detect communication from the port Settings of the controller connected to it. The 1761-NET-ENI is able to force Ethernet to either 11 Mbps or 100 Mbps, as well as default American auto-negotiated half-duplex or full-duplex. Ethernet configuration can be accomplished by configuring security mask Settings.

The most important feature of 1761-NET-ENI is the diagnostic page, which displays important module information and all Ethernet connections in use. The best thing about the 1761-NET-ENI communication interface is that it is efficient and provides excellent output with less power consumption. The 1761-NET-ENI has a maximum operating temperature of 0 to 70 degrees Celsius and a maximum storage temperature of -45 to 85 degrees Celsius. The most commonly used standards are IEC801-2, 3, 4, 5 and 6. The operating humidity is 5-95% without condensation. 1761-NET-ENI's regulations, approvals and certifications include UL, C-UL, CE and Class 1 2 Zone certifications; This module provides Ethernet/IP connectivity for all DF1 full-duplex devices, including all MicroLogix and CompactLogix controllers. This Ethernet interface allows you to upload or download programs, communicate between controllers, and generate email when connected to a non-Ethernet controller.

The 1761-NET-ENI is an Allen-Bradley Advanced Interface Converter (AIC) that enables DF1-enabled devices such as MicroLogix, CompactLogix, SLC 500, PLC5, and third-party devices to connect to EtherNet/IP networks. The converter basically allows point-to-point devices to connect to a multi-node communication network.

The 3-NET-AIC features an isolated 1761-pin mini DIN RS8 port that supports the full-duplex DF232 protocol. Through this port, devices that support DF1 are connected, while Ethernet networks are connected through the provided RJ1 port. The interface converter is installed separately from the PLC, so it does not take up slots for modular PLC or expansion modules. It is powered by an input supply voltage of 45VDC.

The 24-NET-AIC is ideal for multiplexing embedded serial ports of connected devices, allowing older controllers to connect to modern Ethernet networks without the need to add Ethernet communication modules or replace the entire controller. This saves engineering development time and reduces downtime due to commissioning when replacing connected equipment.

1761-NET-ENI是一款Allen-Bradley 接口转换器（AIC）
