产品展示 》 AB 》 1784-PCICS 控制网PCI卡 可以在兼容的计算机上

1784-PCICS 控制网PCI卡 可以在兼容的计算机上

型号:1784-PCICS

1784-PCICS 控制网PCI卡 可以在兼容的计算机上

品牌 艾伦-布拉德利/罗克韦尔自动化
系列 可编程控制器 5
部件号 1784-PCICS
产品类型 控制网PCI卡
兼容插槽 PCI-X, 32 / 64 位 PCI, 3.3 / 5 伏 PCI

1784-PCICS  控制网PCI卡  可以在兼容的计算机上

1784-PCICS卡是Allen-Bradley卡。它是一个PCI卡,可以在兼容的计算机上启用ControlNet连接。在计算机中安装 1784-PCICS 卡的步骤是关闭计算机、卸下计算机机箱盖、选择空置的 PCI 插槽、卸下插槽的扩展盖、处理卡以使其免受 ESD 的影响,zui后将卡插入插槽并拧紧螺钉。

用于卡组件的技术容易受到ESD损坏。因此,应遵循标准的ESD预防措施,例如使用防静电塑料容器,使用接地腕带以及在无静电区域工作。

安装后,1784-PCICS 卡可以直接连接到 ControlNet 网络或已连接到 ControlNet 网络的设备。不同的 ControlNet 网络不应连接到 1784-PCICS 卡,因为这样做会导致通信系统操作不稳定。使用BNC连接器时,卡正面提供的诊断状态指示器提供有关卡和所连接网络的信息。当 1784-PCICS 卡通过 RJ45 网络访问端口连接到 ControlNet 时,状态 LED 毫无意义。1784-PCICS 卡与 PCI-X 插槽、32 位和 64 位 PCI 插槽以及 3.3 伏/5 伏 PCI 插槽兼容。1784-PCICS 卡的尺寸为 107 x 165 毫米。
1784-PCICS  控制网PCI卡  可以在兼容的计算机上

1784-PCICS  控制网PCI卡  可以在兼容的计算机上

The 1784-PCICS card is an Allen-Bradley card. It is a PCI card that enables ControlNet connections on compatible computers. The steps for installing a 1784-PCICS card in a computer are to shut down the computer, remove the computer case cover, select the vacant PCI slot, remove the expansion cover of the slot, process the card to protect it from ESD, and finally insert the card into the slot and tighten the screws.

The technology used in the card components is vulnerable to ESD damage. Therefore, standard ESD precautions should be followed, such as using antistatic plastic containers, using grounded wristbands, and working in static-free areas.

After installation, the 1784-PCICS card can be connected directly to the ControlNet network or to devices already connected to the ControlNet network. Different ControlNet networks should not be connected to 1784-PCICS cards, as doing so will cause the communication system to operate erratically. When using a BNC connector, the diagnostic status indicator provided on the front of the card provides information about the card and the connected network. When the 1784-PCICS card is connected to ControlNet via an RJ45 network access port, the status LED is meaningless. The 1784-PCICS card is compatible with PCI-X slots, 32-bit and 64-bit PCI slots, and 3.3-volt / 5-volt PCI slots. The 1784-PCICS card is 107 x 165 mm in size.

1784-PCICS  控制网PCI卡  可以在兼容的计算机上
