GE DS3800NCT1B1B 卡件 控制器 PLC/DCS系统

GE DS3800NCT1B1B 卡件 控制器 PLC/DCS系统

DS3800NDAC1B1B是Mark IV（Speedtronic）通用电动涡轮机系列的一部分。DS3800NDAC1B1B有一个塑料内孔，有40个尖头空间，还有一个小外孔，有一个带两个紧固件和的彩色小盒子。DS3800NDAC1B1B有25个EPROM。EPROM已编程，但可以在需要改进时重新编程。

DS3800NDAC1B1B还有12个EEPROM。EEPROM已经充满了DS3800NDAC1B1B工作所需的基本数据。DS3800NDAC1B1B有八个蓝色可变电阻器，也称为电位计。

每个可变电阻器的顶部都有一个小引脚，可以自由地相互改变。DS3800NDAC1B1B有一个黄色LED灯，当电流通过时会发光。DS3800NDAC1B1B有一个赤褐色二极管、四个樱桃色二极管、十六个混合尺寸的灰色金属二极管和三十六个蓝色二极管。DS3800NDAC1B1B具有一个单晶振荡器。晶体振荡器用于产生精 确的频率。DS3800NDAC1B1B有74个电阻器，具有多种颜色设计（用于对电流容量进行分类）。DS3800NDAC1B1B有三个薄金属屏障。

有两个定位点和两个紧固件将DS3800NDAC1B1B连接到当前系统。一个边缘标记为A、B、C、D、E、F、G、H和J。DS3800NDAC1B1B在板上有标签。每个部分也都有概述。DS3800NDAC1B1B具有通用电气的徽章，并在其制造地（美国）印制在通用电气徽章下。

GE DS3800NCT1B1B 卡件 控制器 PLC/DCS系统
The DS3800NDAC1B1B is part of the Mark IV (Speedtronic) general purpose electric turbine family. The DS3800NDAC1B1B has a plastic inner hole with 40 prong Spaces, and a small outer hole with a small colored box with two fasteners and. The DS3800NDAC1B1B has 25 EPROMs. The EPROM is programmed, but can be reprogrammed when improvements are needed.

DS3800NDAC1B1B also has 12 EEPROMs. The EEPROM is already full of the basic data needed for DS3800NDAC1B1B to work. The DS3800NDAC1B1B has eight blue variable resistors, also known as potentiometers.

Each variable resistor has a small pin at the top that can freely change with each other. The DS3800NDAC1B1B has a yellow LED light that glows when an electric current passes through it. The DS3800NDAC1B1B has one russet diode, four cherry diodes, sixteen mixed-size gray metal diodes, and thirty-six blue diodes. The DS3800NDAC1B1B has a single crystal oscillator. Crystal oscillators are used to produce precise frequencies. The DS3800NDAC1B1B has 74 resistors in a variety of color designs (for classifying current capacity). The DS3800NDAC1B1B has three thin metal barriers.

There are two anchor points and two fasteners that connect the DS3800NDAC1B1B to the current system. One edge is labeled A, B, C, D, E, F, G, H, and J. DS3800NDAC1B1B has a label on the board. Each section is also outlined. The DS3800NDAC1B1B bears the GE badge and is printed under the GE badge in its place of manufacture (USA).

GE DS3800NCT1B1B 卡件 控制器 PLC/DCS系统
