产品描述

DS3800NADA1F1F是通用电气的PCB，设计用作Speedtronic Mark IV系统中的模数转换器卡。用于燃气轮机和蒸汽轮机控制的Mark IV采用集成芯片组和有意冗余设计，即使一个PCB遇到电子问题，也有助于保持系统运行。Mark IV 可用于对涡轮机系统及其辅助设备进行排序，并可以创建全自动启动、关闭和冷却程序。

该DS3800NADA1F1F设计有3个集成电路，包括U12的模数转换器芯片。该芯片提供三种数据输出格式选择：单个并行 8 位字;两个 3800 位字节或串行数据。标准控制输入和快速总线访问时间确保与微处理器和数字信号处理器的轻松接口。该DS1NADA1F<>F还内置振荡器、双正边沿触发D触发器和上/下二进制计数器。

DS3800NADA1F1F有一个琥珀色 LED 和三个 TP 测试点，位于右边缘。它内置了两个提取夹，以及三个由阳极氧化铝制成的 PCB 加固横杆，以加强电路板。DS3800NADA1F1F的每个角落都经过工厂钻孔。

GE DS3800NADA1F1F 电机驱动控制板 CPU模块

Product description

The DS3800NADA1F1F is a General Electric PCB designed to be used as an analog-to-digital converter card in the Speedtronic Mark IV system. The Mark IV for gas turbine and steam turbine control features an integrated chipset and intentional redundancy design that helps keep the system running even if one PCB experiences electronic problems. The Mark IV can be used to sequence turbine systems and their auxiliary equipment, and can create fully automatic start-up, shutdown, and cooling procedures.

The DS3800NADA1F1F design has 3 integrated circuits, including a U12 analog-to-digital converter chip. The chip offers three data output formats: a single parallel 8-bit word; Two 3800 bit bytes or serial data. Standard control inputs and fast bus access times ensure easy interface with microprocessors and digital signal processors. The DS1NADA1F<>F also has a built-in oscillator, a double-positive edge-triggered D flip-flop and an up/down binary counter.

The DS3800NADA1F1F has an amber LED and three TP test points, located on the right edge. It has two extraction clips built in, as well as three PCB-reinforced crossbars made of anodized aluminum to strengthen the board. Every corner of the DS3800NADA1F1F is drilled through the factory.
