GE DS3800HXRC 是一块电路板 带有 18 个跳线开关

GE DS3800HXRC 是一块电路板 带有 18 个跳线开关

产品描述

产品描述

DS3800HXRC是一种印刷电路板（PCB），旨在成为通用电气Mark IV系列的一部分。Mark IV 是为燃气轮机和蒸汽轮机控制而设计的。该系统可用于监控涡轮机及其辅助设备，对启动和关闭程序进行排序，并使整个系统在安全参数范围内运行。它还可用于空气、水和燃料排放控制。

该DS3800HXRC已作为系列6接收器生产。它还充当DS3800DXRC的主板， 可以通过连接到位于电路板中间的端口的带状电缆连接到该印刷电路板.DS3800DXRC是一块电路板，带有 18 个跳线开关、一个拨动开关、一个红色 LED、4 个 TP 点和多个集成电路。

DS3800HXRC具有以下规格：

工厂钻孔，夹子连接到两个角

标记为 6BA03。标记在板的顶部以进行对齐。

填充了四个连接器。这包括上面提到的带状连接器。它还在一侧边缘具有 218A44553-1 连接器，在另一边缘具有两个公连接器。

有两个晶体管位于电路板的左下象限

拥有48个集成电路。

设计有多个跳线开关、电阻网络和金属膜电阻器。跳线允许用户通过更改跳线的位置来更改电路板的某些方面。

GE DS3800HXRC 是一块电路板 带有 18 个跳线开关

Product description

The DS3800HXRC is a printed circuit board (PCB) designed to be part of the General Electric Mark IV series. The Mark IV is designed for gas and steam turbine control. The system can be used to monitor the turbine and its auxiliary equipment, sequence start-up and shutdown procedures, and keep the entire system operating within safe parameters. It can also be used for air, water and fuel emission control.

The DS3800HXRC has been produced as a Series 6 receiver. It also acts as a motherboard for the DS3800DXRC, which can be connected to the printed circuit board by a ribbon cable connected to a port located in the middle of the board. The DS3800DXRC is a circuit board with 18 jumper switches, a toggle switch, a red LED, 4 TP points, and multiple integrated circuits.

The DS3800HXRC has the following specifications:

Factory drilling, clamps connected to two corners

Labeled 6BA03. Mark the top of the board for alignment.

Four connectors are filled. This includes the ribbon connectors mentioned above. It also has 218A44553-1 connectors on one edge and two male connectors on the other edge.

There are two transistors located in the lower left quadrant of the board

It has 48 integrated circuits.

Designed with multiple jumper switches, resistance networks and metal film resistors. The jumper allows the user to change certain aspects of the board by changing the position of the jumper.
