IC200ALG328J GE 模块提供 12 个输出

IC200ALG328J GE 模块提供 12 个输出

IC200ALG328模块是由GE Fanuc Automation设计和制造的Versamax I / O模块。这个特定的模块提供 12 个输出。这些输出是模拟电流源类型的输出，它们可以在 4 至 20 毫安的电流范围内工作。该模块每通道具有 20.38 毫安电流来驱动输出负载，尽管这些通道需要外部电源才能正常工作。

GE Fanuc Automation IC200ALG328 Versamax I/O 模块的通道可以使用IC200ALG326模块的通道进行缩放，因为它们的特性相似且兼容。该模块还与以太网、Genius、Profibus 和 DeviceNet 固件兼容。它还与PLC CPU固件和VersaPro软件兼容。

GE Fanuc Automation IC200ALG328 Versamax I/O 模块仅在 30 伏直流电下使用并放置在 DIN 导轨上的某个位置时才具有热降额。这种降额还取决于存在的环境空气温度。GE Fanuc Automation IC200ALG328 Versamax I/O 模块的额定电压为 18 至 30 伏直流电，额定电流消耗为 2 安培浪涌电流，无负载时的额定功耗为 100 毫安，满量程使用所有 270 个输出时的额定功耗为 12 毫安。该模块的分辨率为13位，精度等级高达1%。该模块配有 2 个 LED 指示灯和诊断工具，可以热插入，但这需要小心完成，以保留机架和模块中的所有组件。

IC200ALG328J GE 模块提供 12 个输出

The IC200ALG328 module is a Versamax I/O module designed and manufactured by GE Fanuc Automation. This particular module provides 12 outputs. These outputs are analog current source type outputs, and they can operate in the current range of 4 to 20 mA. The module has 20.38 milliamps per channel to drive the output load, although these channels require an external power supply to function properly.

The channels of the GE Fanuc Automation IC200ALG328 Versamax I/O module can be scaled using the channels of the IC200ALG326 module because their characteristics are similar and compatible. The module is also compatible with Ethernet, Genius, Profibus and DeviceNet firmware. It is also compatible with PLC CPU firmware and VersaPro software.

The GE Fanuc Automation IC200ALG328 Versamax I/O module is thermal derated only when used at 30 volts DC and placed at a certain position on the DIN rail. This derating also depends on the ambient air temperature present. GE Fanuc Automation IC200ALG328 Versamax I/O modules are rated from 18 to 30 volts DC, rated current consumption is 2 amps inrush current, and rated power consumption is 100 mA when unloaded. Power consumption is rated at 12 mA when using all 270 outputs at full scale. The module has a resolution of 13 bits and an accuracy level of up to 1%. Equipped with 2 LED indicators and diagnostic tools, the module can be hot-plugged in, but this needs to be done carefully to retain all the components in the rack and module.

IC200ALG328J GE 模块提供 12 个输出
