产品描述

GE微处理器扩展板DS3800HXPD1C1D设计用于在驱动器中快速安装。该板的一端有一个模块化连接器，另一端有一个固定杆。GE微处理器扩展板DS1HXPD3800C1D在固定杆之间还装有1个2针连接器。该板还装有 34 个用于电可擦除可编程只读存储器 （EEPROM） 模块的插座和 8 个跳线。

GE 微处理器扩展板DS18HXPD3800C1D上的 1 个跳线由安装人员用于配置板。当您收到从工厂购买的第 一块板时，跳线设置为默认位置。即zui 常用的职位。安装说明描述了跳线以及设置如何影响电路板的功能。安装程序应咨询操作员和工程师，以决定如何使用配置设置。跳线称为 3 针跳线。跳线适合 2 个以上的跳线，移动跳线会改变配置。跳线可以位于引脚 1 和 2 或引脚 2 和 3 上。覆盖引脚之间产生信号，影响配置。

设置跳线后，zui 佳做法是记录设置并将其存储在安全的地方。更换主板时，请参阅跳线设置记录并匹配更换板上的设置。切勿用力将跳线插入 2 个引脚以上。它可能会弯曲引脚或将它们从板上折断。

GE DS3800HXPD1C1D 用于电可擦除可编程只读存储器

Product description

The GE microprocessor expansion board DS3800HXPD1C1D is designed for quick installation in drives. The board has a modular connector at one end and a fixed rod at the other end. The GE microprocessor expansion board DS1HXPD3800C1D also has a 2-pin connector between the fixed rods. The board is also equipped with 34 sockets for electrically erasable programmable read-only memory (EEPROM) modules and 8 jumpers.

One jumper on the GE microprocessor expansion board DS18HXPD3800C1D is used by the installer to configure the board. When you receive your first board purchased from the factory, the jumper is set to the default position. The most commonly used position. The installation instructions describe the jumpers and how the Settings affect the board's functionality. The installer should consult with the operator and engineer to determine how to use the configuration Settings. The jumper is called a 3-pin jumper. The jumper is suitable for more than 2 jumpers, and moving the jumper will change the configuration. Jumpers can be located on pins 1 and 2 or pins 2 and 3. A signal is generated between the overlay pins, affecting the configuration.

After setting the jumper, the best practice is to record the Settings and store them in a safe place. When replacing the motherboard, refer to the jumper setup record and match the Settings on the replacement board. Do not force the jumper into more than 2 pins. It may bend the pins or snap them off the board.
