GE DS3800HXPC1D1F CPU扩展板 有48个集成电路

GE DS3800HXPC1D1F CPU扩展板 有48个集成电路

产品描述

DS3800HXPC1D1F是通用电气制造的CPU扩展板，作为其Mark IV系列的一部分。Mark IV（Speedtronic）是一种燃气和蒸汽轮机控制系统。它专为涡轮机控制的各个方面而设计，包括发电机与系统的同步和电压匹配、监控辅助功能、对系统进行启动和冷却排序，以及保护系统免受不安全运行条件的影响。

该DS3800HXPC1D1F有48个集成电路。这包括内部定时器电路，如英特尔的 D8254 L4380686。它还具有可编程中断控制器，如AMD P8259A 8710DP，以及八通道缓冲器和线路驱动器PDIP，如德州仪器的SN74LS244N。DS3800HXPC1D1F具有 37 个跳线开关，分布在各个电路板上。其中一些是多位置的。它还具有六个电阻网络，可以放置在电路板上以进行数据转换或分压。

DS3800HXPC1D1F可以通过两个公连接器 （218A4637-P2） 和一个母连接器 （218A4553-1 AMP 533002-1 8706） 连接到其他辅助设备。它已在工厂的各个角落钻孔，夹子安装在其中两个孔中。

DS3800HXPC1D1F上的标记包括下边缘的“6BA04”和“ADS/WMH/EFO”。它的上边缘标记为 A 到 J。该板在位于其左边缘的母连接器后面编号了数十个。该DS3800HXPC1D1F使用铝电解电容器和陶瓷覆盖的金属膜电阻器。

GE DS3800HXPC1D1F CPU扩展板 有48个集成电路

Product description

The DS3800HXPC1D1F is a CPU expansion board manufactured by General Electric as part of its Mark IV series. The Mark IV (Speedtronic) is a gas and steam turbine control system. It is designed for all aspects of turbine control, including generator synchronization and voltage matching with the system, monitoring auxiliary functions, sequencing the system for start-up and cooling, and protecting the system from unsafe operating conditions.

The DS3800HXPC1D1F has 48 integrated circuits. This includes internal timer circuits such as Intel's D8254 L4380686. It also features a programmable interrupt controller, such as the AMD P8259A 8710DP, and an eight-channel buffer and line driver PDIP, such as Texas Instruments' SN74LS244N. The DS3800HXPC1D1F has 37 jumper switches distributed on various boards. Some of them are multi-location. It also has six resistor networks that can be placed on the circuit board for data conversion or voltage division.

The DS3800HXPC1D1F can be connected to other auxiliary devices via two male connectors (218A4637-P2) and one female connector (218A4533-1 AMP 533002-1 8706). It has been drilled in various corners of the plant, with clamps installed in two of the holes.

The markings on the DS3800HXPC1D1F include "6BA04" and "ADS/WMH/EFO" on the lower edge. Its top edges are labeled A through J. The board is numbered dozens behind a female connector located on its left edge. The DS3800HXPC1D1F uses an aluminum electrolytic capacitor and a metal-film resistor covered with ceramic.
