产品描述

GE 内存扩展板DS3800HXPA1F1H专为快速安装在驱动器中而设计。该板的一端有一个模块化连接器，另一端有一个固定杆。GE 内存扩展板DS1HXPA3800F1H在固定杆之间还装有 1 个 3 针连接器。该板还装有多个电可擦除可编程只读存储器 （EEPROM） 模块和 40 个琥珀色指示灯 LED。

GE 内存扩展板DS3800HXPA1F1H为正常处理活动提供额外的内存。通过控制信号，存储器由驱动器中的微处理器和其他逻辑器件访问。信号通过模块化连接器传输。一个模块化连接器位于板上，与固定杆相对。驱动器在板架末端配备了另一个模块化连接器。安装电路板时，模块化连接器已配接。用拇指将模块化连接器压在一起。固定杆可固定连接。

其他信号通过连接到固定杆之间的 40 针连接器的带状电缆传输。一个 40 针连接器可接受带固定螺钉的带状电缆。要使用外加固定螺钉，请将带状电缆连接器压入主板上的连接器。用手或螺丝刀固定固定螺钉。

GE DS3800HXPA1F1H 内存扩展板 装有 1 个 3 针连接器

Product description

The GE memory expansion board DS3800HXPA1F1H is designed for quick installation in a drive. The board has a modular connector at one end and a fixed rod at the other end. The GE memory expansion board DS1HXPA3800F1H also has a 3-pin connector between the fixing rods. The board also houses multiple electrically erasable programmable read-only memory (EEPROM) modules and 40 amber indicator leds.

The GE memory expansion board DS3800HXPA1F1H provides additional memory for normal processing activities. Through control signals, the memory is accessed by microprocessors and other logic devices in the drive. Signals are transmitted through modular connectors. A modular connector is located on the board opposite the fixed rod. The driver is equipped with another modular connector at the end of the board frame. When installing a circuit board, a modular connector has been installed. Press the modular connectors together with your thumb. Fixed rod can be fixed connection.

Other signals are transmitted via a ribbon cable connected to a 40-pin connector between the fixed rods. A 40-pin connector accepts ribbon cable with set screws. To use additional set screws, press the ribbon cable connector into the connector on the motherboard. Use your hand or a screwdriver to secure the set screws.
