GE DS3800HXPA1D1D 存储器由EEPROM模块提供

GE DS3800HXPA1D1D 存储器由EEPROM模块提供

产品描述

GE 内存扩展板DS3800HXPA1D1D专为快速安装在驱动器中而设计。该板的一端有一个模块化连接器，另一端有一个固定杆。GE 内存扩展板DS1HXPA3800D1D在固定杆之间还装有 1 个 3 针连接器。该板还装有多个电可擦除可编程只读存储器 （EEPROM） 模块和 40 个琥珀色指示灯 LED。

GE 内存扩展板DS3800HXPA1D1D旨在为驱动器中的其他主板提供额外的内存。一些存储器由EEPROM模块提供。存储器用于存储用于控制其他板上的微处理器和晶体管到晶体管组件的代码。安装程序可以将相应的模块插入模块插槽以控制组件。插入后，技术人员可以将电路板安装在机架中。然后为驱动器通电。驱动器将从模块读取代码以控制处理。

安装模块时，必须特别注意保护电路板免受静电的影响。技术人员必须始终随身携带并使用腕带。这可以保护组件免受静电损坏。静电从人流到腕带另一端的接地表面。金属表面可以是适当的接地表面。例如，工作区中的金属桌腿、工作台或金属搁板。夹子用于将表带连接到金属表面。一些表带使用特制的插头，在金属表面上带有插座。

GE DS3800HXPA1D1D 存储器由EEPROM模块提供

Product description

The GE memory expansion board DS3800HXPA1D1D is designed for quick installation in a drive. The board has a modular connector at one end and a fixed rod at the other end. The GE memory expansion board DS1HXPA3800D1D also has a 3-pin connector between the fixed rods. The board also houses multiple electrically erasable programmable read-only memory (EEPROM) modules and 40 amber indicator leds.

The GE memory expansion board DS3800HXPA1D1D is designed to provide additional memory for other motherboards in the drive. Some memory is provided by an EEPROM module. The memory is used to store code for controlling microprocessors and transistor-to-transistor components on other boards. The installer can insert the corresponding module into the module slot to control the component. After insertion, the technician can mount the board in the rack. Then power the drive. The driver will read the code from the module to control the processing.

When installing a module, pay special attention to protecting the circuit board from static electricity. Technicians must carry and use a wristband at all times. This protects the components from electrostatic damage. Static electricity flows from the wrist strap to the ground surface at the other end. The metal surface may be a suitable ground surface. For example, a metal table leg, workbench, or shelf in a work area. Clips are used to attach the band to the metal surface. Some bands use a special plug with a socket on the metal surface.
