GE DS3800HVDB1K1G 一端有一个模块化连接器

GE DS3800HVDB1K1G 一端有一个模块化连接器

GE视频驱动板DS3800HVDB1K1G专为在驱动器中快速安装而设计。该板的一端有一个模块化连接器，另一端有固定杆。GE视频驱动板DS3800HVDB1K1G在固定杆之间也装有1个20针连接器。该板还装有多个电可擦除可编程只读存储器（EPROM）模块和15个跳线。

EEPROM模块存储固件和控制驱动器上处理的其他代码。收到原始主板后，将继续开发固件和编程说明，以改进驱动器处理。该代码会更新修复程序以解决已知错误。它还变得更加可靠，并更新了新的功能和特性。但是，必须将zui新的代码加载到驱动器中的模块上。只有这样，驱动器才能从代码更新中受益。

模块可以在不必将其从板上移除的情况下进行更新。也就是说，它们可以通过电子方式进行更新。这意味着操作员可以始终使用zui新的固件更新。操作员还可以确保驱动器具有zui新的编程代码。

但是，在更换电路板时，必须卸下模块。如果由于组件或电路板故障导致电路板无法修复，zui好的选择是更换GE视频驱动板DS3800HVDB1K1G。更换板在模块插座中未安装模块。模块的拆卸不需要专用工具。只能使用螺丝刀撬开模块。要安装模块，请将其放置在插座上，然后将其压入到位。

GE DS3800HVDB1K1G 一端有一个模块化连接器

The GE video driver board DS3800HVDB1K1G is designed for quick installation in the drive. The board has a modular connector at one end and a fixed rod at the other end. The GE video driver board DS3800HVDB1K1G also has a 20-pin connector between the fixed rods. The board also houses multiple electrically erasable programmable read-only memory (EPROM) modules and 15 jumpers.

The EEPROM module stores firmware and other code processed on the control drive. After receiving the original motherboard, firmware and programming instructions continue to be developed to improve drive handling. The code updates fixes to address known errors. It has also become more reliable and updated with new functions and features. However, the latest code must be loaded onto the module in the drive. Only in this way can the drive benefit from code updates.

Modules can be updated without having to be removed from the board. That is, they can be updated electronically. This means that operators can always use the latest firmware updates. The operator can also ensure that the drive has the latest programming code.

However, when replacing the board, the module must be removed. If the board cannot be repaired due to component or board failure, the best option is to replace the GE video driver board DS3800HVDB1K1G. Replacement board No module is installed in the module socket. No special tools are required for module disassembly. Only use a screwdriver to pry open the module. To install the module, place it on the socket and press it into place.

GE DS3800HVDB1K1G 一端有一个模块化连接器
