GE 低 HP 序列板DS3800HSQD1H1E设计为每个角上都有一个孔，用于插入螺钉以将板固定在驱动器中。GE 低 HP 序列板DS1HSQD3800H1E还配备了 1 个 2 针连接器和 40 个带固定杆的 1 针连接器，用于固定带状电缆。该板还装有 20 针连接器和 50 个 1 针连接器。该板还装有 20 个可擦除可编程只读存储器 （EPROM） 模块和 1 个琥珀色指示灯 LED 和 1 个红色指示灯 LED。

GE 低 HP 序列板DS50HSQD3800H1E上的 1 针连接器具有与板处理相关的特定用途。它将开发板连接到专门为该开发板构建的子卡。子卡通过在卡每个角的匹配孔上滑动来连接到支架。锁定到位后，卡会卡住支架。子卡连接了 1 根 50 针带状电缆。一端永 久连接到卡上，另一端连接着一个 1 针连接器。将 50 针连接器连接到主板。它提供用于接收和发送子卡控制信号的连接。它还提供为子卡供电所需的电流。

由于连接了子卡的GE Low HP序列板DS3800HSQD1H1E的重量和尺寸额外，因此在主板机架中安装主板时要小心。

GE DS3800HSQD1H1E 1 针连接器具有与板处理相关的特定用途

The GE Low HP serial board DS3800HSQD1H1E is designed with a hole in each corner for inserting screws to secure the board in the drive. The GE Low HP serial board DS1HSQD3800H1E also comes with 1 2-pin connector and 40 1-pin connectors with fixed rods for securing ribbon cables. The board is also equipped with 20-pin connectors and 50 1-pin connectors. The board is also equipped with 20 erasable programmable read-only memory (EPROM) modules and one amber LED and one red LED.

The 1-pin connector on the GE low HP serial board DS50HSQD3800H1E has specific uses related to board handling. It connects the development board to a sub-card built specifically for that development board. The sub-card is attached to the bracket by sliding over the matching hole at each corner of the card. With the lock in place, the card will jam the bracket. The sub-card is connected to a 50-pin ribbon cable. One end is permanently attached to the card and the other end is connected to a 1-pin connector. Connect the 50-pin connector to the motherboard. It provides connections for receiving and sending control signals from the daughter card. It also provides the current needed to power the daughter card.

Due to the extra weight and size of the GE Low HP sequence board DS3800HSQD1H1E with the subcard attached, care should be taken when installing the motherboard in the motherboard rack.
