产品描述

GE涡轮机控制板DS3800HCIB1B1C具有用于连接到驱动器的模块化连接器和固定杆，用于将板固定在驱动器中。GE 涡轮机控制板DS3800HCIB1B1C还配有 1 个跳线和 1 个琥珀色 LED 指示灯。该板还具有 1 个 20 针连接器、1 个 50 针连接器和多个电容器。

当板安装在机架中时，操作员可以使用 20 针连接器和 50 针连接器。连接器位于固定杆之间，其设计使技术人员可以在将电路板安装在机架中时卸下或连接电缆。在计划安装带状电缆之前，需要牢记一些注意事项。首先，如果带状电缆布线不正确，它们可能会阻塞驱动器内部的气流。

驱动器中的组件在正常加工过程中会产生热量，如果允许热量积聚，热量会导致组件寿命缩短并增加驱动器的停机时间。它可能会导致过热跳闸情况，从而导致驱动器自行关闭。避免这种情况的zui佳方法是让气源通过底部通风口进入驱动器。空气被组件加热，并通过驱动器顶部的通风口离开驱动器。将电缆远离通风口，以免热量积聚在驱动器中。

GE DS3800HCIB1B1C 涡轮机控制板 用于将板固定在驱动器中
Product description

The GE turbine control board DS3800HCIB1B1C has modular connectors for connection to the drive and retainer rods for securing the board in the drive. The GE turbine control panel DS3800HCIB1B1C is also equipped with a jumper and an amber LED indicator. The board also has a 20-pin connector, a 50-pin connector, and multiple capacitors.

When the board is mounted in a rack, the operator can use both 20-pin connectors and 50-pin connectors. The connectors are located between the fixed rods and are designed so that the technician can remove or connect the cables while mounting the board in the rack. There are a few considerations to keep in mind before planning to install ribbon cables. First, if the ribbon cables are not routed correctly, they may block the airflow inside the driver.

The components in the drive generate heat during normal machining, and if the heat is allowed to build up, the heat can lead to shortened component life and increased downtime for the drive. It can cause an overheat trip situation, which causes the drive to shut down on its own. The best way to avoid this is to let the air source into the drive through the bottom vent. The air is heated by the assembly and leaves the drive through a vent at the top of the drive. Keep the cable away from the vents so that heat does not build up in the drive.
