3500/22M 特点
在 3500 机架中，TDI 位于电源旁边的插槽中。为了持续收集稳态和瞬态动态（波形）数据并通过以太网链路将此数据传输到主机软件，它与 M 系列监视器（3500/40M、3500/42M 等）交互。

TDI 具有传统的静态数据收集功能。然而，TDI 也可以使用可选的通道启用磁盘记录动态、高分辨率的瞬态数据。

功能说明
3500 机架包含 TDI 的通信处理功能。虽然 TDI 执行一些由整个机架共享的任务，但它不是监控系统的关键组件，并且与整个系统监控自主机械保护的效果无关。

每个 3500 机架需要一个 TDI 或 RIM，它始终占用插槽 1。（电源旁边）。

3500 监测系统和兼容软件之间的链接称为 3500/22M 瞬态数据接口 (TDI)（系统 1 状态监测和诊断软件和 3500 系统配置软件）。TDI 将 3500/20 机架接口模块 (RIMfunctionality ) 与通信处理器（如 TDXnet）相结合，以收集数据。

BENTLY 3500/22M 本特利状态监测系统

3500/22M features
In the 3500 rack, the TDI is located in the slot next to the power supply. It interacts with M-series monitors (3500/40M, 3500/42M, etc.) in order to continuously collect steady-state and transient dynamic (waveform) data and transmit this data to the host software over an Ethernet link.

TDI has traditional static data collection capabilities. However, TDI can also enable the disk to record dynamic, high-resolution transient data using an optional channel.

Function description
The 3500 rack contains the communication processing capabilities of TDI. While TDI performs some tasks shared by the entire rack, it is not a critical component of the monitoring system and is not relevant to how well the entire system monitors autonomous mechanical protection.

Each 3500 rack requires a TDI or RIM, which always occupies slot 1. (Next to the power supply).

The link between the 3500 monitoring system and compatible software is called the 3500/22M Transient Data Interface (TDI) (System 1 condition monitoring and diagnostic software and 3500 system configuration software). TDI combines 3500/20 rack interface modules (RIMfunctionality) with communication processors such as TDXnet to collect data.
