继电器模块组态事项

●在组态继电器模块之前，先将监测器模块加到框架组态上。

●只将要用到的继电器块通道激活。

●在报警驱动逻辑器中，只有监测器模块可能被用到。

●只有三重模冗余组的第 一个监测器模块，需要加到报警驱动逻辑器上。

●如果一条通道产生一个报警，而这个报瞥是与(AND)运算器的一部分，并且该通道被旁路，则被旁路的通道运算值为真。由于旁路，报警不会被抑制。

●如果一条通道产生一个报警，而这个报警是或(OR) 运算器的一 部分，并且该通道被旁路，则被旁路的通道运算值为假。

●对于一个四通道标准继电器，对整个继电器组态来说，产生的指令不会超过60条。能被继电器所接收的指令数，也依赖于继电器程序语言的版本。高于等于(≥) 2. 0版的继电器程序语言,将能接收更加复杂的继电器报警驱动逻辑方程。在发送之前，程序语言的版本将被检查，同时将决定继电器是否能接收指令设置。

BENTLY 3500/33 持续测量和监测各种保护和监督

Relay module configuration matters

● Add the monitor module to the frame configuration before configuring the relay module.

● Only the relay block channel that will be used is activated.

● In the alarm driver logic, only the monitor module may be used.

● The first monitor module with only triple mode redundancy needs to be added to the alarm driver logic.

If a channel generates an alarm that is part of the AND (AND) operator and the channel is bypassed, then the bypassed channel operation is true. Because of the bypass, the alarm is not suppressed.

● If a channel generates an alarm that is part of an OR (OR) operator and the channel is bypassed, the bypassed channel operation is false.

● For a four-channel standard relay, no more than 60 instructions are generated for the entire relay configuration. The number of instructions that can be received by the relay also depends on the version of the relay programming language. A relay programming language greater than or equal to (≥) version 2.0 will be able to accept more complex relay alarm drive logic equations. Before sending, the version of the program language will be checked and it will be determined whether the relay can receive the instruction Settings.
