3500/92 功能说明
对于 10BASE-T 星型配置以太网，3500/92 的以太网连接是 RJ45 连接。除了主要值 Modbus 寄存器外，3500/92 支持原始 3500/90 的通信接口、通信协议和附加功能。3500/92 中的主要值 Modbus 寄存器被可配置的 Modbus 寄存器实用程序所取代，现在可以提供相同的功能。

能量消耗
使用 ModbusRS232/RS422 I/O 模块时典型值为 5.0 瓦

使用 Modbus RS485 I/O 模块时典型值为 5.6 瓦

3500/92 数据类型
利用高速内部网络从机架中的其他模块收集信息，包括带有时间戳的当前测量值、模块状态和当前警报状态。

返回的确切数据类型取决于通道配置和模块类型。
更新时间：3500 机架中所有模块的数据采集速率不会大于 1 秒，具体取决于机架的设计。

机架空间要求
监控模块 - 1 个全高前插槽

I/O 模块 - 1 个全高后插槽

Bently 3500/92 框架监测数据和状态通讯网关

3500/92 Function Description
For 10BASE-T star configuration Ethernet, the 3500/92 Ethernet connection is an RJ45 connection. In addition to the main value Modbus register, the 3500/92 supports the communication interface, communication protocol, and additional features of the original 3500/90. The primary value Modbus register in 3500/92 was replaced by the configurable Modbus register utility, which now provides the same functionality.

Energy consumption
The typical value when using the ModbusRS232/RS422 I/O module is 5.0 watts

The typical value is 5.6 watts when using the Modbus RS485 I/O module

3500/92 data type
Use a high-speed internal network to gather information from other modules in the rack, including time-stamped current measurements, module status, and current alert status.

The exact data type returned depends on the channel configuration and module type.
Update time: The data acquisition rate for all modules in the 3500 rack will not be greater than 1 second, depending on the rack design.

Rack space requirement
Monitoring module - One full-height front slot

I/O module - 1 full height rear slot
