IC695CPE310 GE 中央处理器模块 2插槽CPU

IC695CPE310 GE 中央处理器模块 2插槽CPU

IC695CPE310 是 GE Fanuc PACSystem RX3i 系列中的一款 CPU。CPU 可以对机器、过程和材料处理系统进行实时控制。它通过双用途 PCI 和串行背板与 I/O 和智能选项模块通信。

IC695CPE310 具有 1.1 GHz Atom 处理器和 10 MB 内存。其嵌入式以太网接口可容纳两个额定速率为 10Mb/秒和 100Mb/秒的连接。它还具有 RS-485 和 RS-232 串行端口。该模块zui多支持 512 个程序块，每个程序块zui大可达 128 KB。IC695CPE310 包含 Modbus RTU Slave、SNP 和 Serial I/O 协议，同时使用 SNP 协议与人机界面 (HMI) 设备进行通信。

您可以使用梯形图、结构化文本、C 或功能块图编程语言对 IC695CPE310 进行编程。当设备通电时，设备外壳上标记的 LED 指示灯可以呈绿色、红色、熄灭或闪烁。这使故障排除变得高效，并让您一目了然地验证系统状态。

IC695CPE310 可以安装在主 RX3i 控制器机架中的任何一对插槽中，除了两个zui大编号的插槽。

IC695CPE310 中的处理器比其他方面相似的型号 C695CPU310 中的 300 MHz Celeron 处理器快大约三倍。您可以从 CPU310 升级到 CPE310，而无需更改旧版 PME 软件。请注意，如果您决定从 CPU310 升级到 CPE310，则 CPE310 上的 RS-232 端口不会在引脚 5 上提供 5V 电源。

IC695CPE310 GE 中央处理器模块 2插槽CPU

The IC695CPE310 is a CPU in the GE Fanuc PACSystem RX3i family. The CPU provides real-time control of machines, processes, and material handling systems. It communicates with the I/O and Smart Options modules via dual-purpose PCI and serial backplanes.

The IC695CPE310 has a 1.1GHz Atom processor and 10 MB of RAM. Its embedded Ethernet interface can accommodate two connections rated at 10Mb/ s and 100Mb/ s. It also has RS-485 and RS-232 serial ports. The module supports up to 512 blocks, each up to 128 KB. The IC695CPE310 contains the Modbus RTU Slave, SNP, and Serial I/O protocols, while using the SNP protocol to communicate with human machine interface (HMI) devices.

You can program the IC695CPE310 using ladder diagram, structured text, C, or function Block diagram programming languages. When the device is powered on, the LED indicator marked on the device housing can be green, red, off, or blinking. This makes troubleshooting efficient and allows you to verify system status at a glance.

The IC695CPE310 can be installed in any pair of slots in the main RX3i controller rack except for the two maximum numbered slots.

The processor in the IC695CPE310 is about three times faster than the 300 MHz Celeron processor in the otherwise similar C695CPU310. You can upgrade from CPU310 to CPE310 without changing legacy PME software. Note that if you decide to upgrade from CPU310 to CPE310, the RS-232 port on the CPE310 will not provide 5V power on pin 5.

IC695CPE310 GE 中央处理器模块 2插槽CPU
