IC697CPM790是 90-70 系列可编程逻辑控制器 （PLC） CPU。该 CPU 是一个单插槽宽的模块，专门用于关键应用，例如紧急停机系统、火灾、燃气和其他应用。该 CPU 通过整合独立的 C 程序来支持三重媒体冗余 （TMR），以启用自动测试例程。

该IC697CPM790具有 1 MB 的电池备份内存，zui高 512KB 可供使用梯形图编程语言配置的用户程序使用。当配置为单工模式时，此 CPU 支持多达 12K 的任意组合的离散输入和输出点;2048 个投票的离散输入和 2048 个投票的离散输出。同样，该IC697CPM790能够处理高达 8K 的模拟输入和输出，在单工模式下运行时可处理任意组合的模拟输入和输出，并具有 1024 个投票模拟输入。它配备了时钟速度为 80486 MHz 的 2DX64 微处理器。该 CPU 具有相对较快的扫描速率，每个布尔函数 0.4 微秒，适用于关键应用。

该IC697CPM790支持三重模块化冗余 （TMR），用于使系统不会停机。这种 TMR 设置基本上由三重 PLC 机架组成，每个机架具有一 （1） 个IC697CPM790 CPU、三重 Genius I/O 总线，以及三重输入传感器和三重输出负载。

IC697CPM790 配有一 （1） 个 15 针 sub-D 连接器，可与 RS485 兼容设备通信。其他形式的通信，例如连接到编程计算机，可以使用部件号为 IC422ACC485 的 RS-232/RS-690 至 RS-900 转换器或部件号为 IC232ACC422 的 RS-690 至 RS-901 微型转换器来建立。

IC697CPM790可编程控制器 CPU 还适用于关键的工业和商业安全相关应用，例如火灾和气体相关应用以及 ESD 或紧急关机系统。它使用 Windows 或 MS-DOS 软件进行编程，并能够通过机架安装背板与安装它的同一 PLC 系统中的 I/O 模块和智能选件模块进行通信。IC697CPM790可编程控制器 CPU 无法运行，除非独立 C 程序作为 CPU 加载的应用程序的一部分包含在内。

IC697CPM790-GD GE 该 CPU是一个单插槽宽的模块

The IC697CPM790 is a 90-70 series Programmable Logic controller (PLC) CPU. The CPU is a single slot wide module designed for critical applications such as emergency shutdown systems, fire, gas and other applications. The CPU supports triple media redundancy (TMR) by integrating separate C programs to enable automated test routines.

The IC697CPM790 has 1 MB of battery backup memory and up to 512KB is available for user programs configured using the ladder diagram programming language. When configured in simplex mode, this CPU supports any combination of discrete input and output points up to 12K; Discrete input of 2048 votes and discrete output of 2048 votes. Similarly, the IC697CPM790 is capable of handling analog inputs and outputs up to 8K, can handle any combination of analog inputs and outputs when run in simplex mode, and has 1024 voting analog inputs. It is equipped with a 2DX64 microprocessor with a clock speed of 80486 MHz. The CPU has a relatively fast scan rate of 0.4 microseconds per Boolean function, which is suitable for critical applications.

The IC697CPM790 supports Triple modular redundancy (TMR) for system downtime. This TMR setup essentially consists of triple PLC racks, each with one (1) IC697CPM790 CPU, triple Genius I/O bus, and triple input sensors and triple output loads.

The IC697CPM790 is equipped with one (1) 15-pin sub-D connector for communication with RS485 compatible devices. Other forms of communication, such as connection to a programmed computer, can be established using RS-232/RS-690 to RS-900 converters with part number IC422ACC485 or RS-690 to RS-901 microconverters with part number IC232ACC422.

The IC697CPM790 programmable controller CPU is also suitable for critical industrial and commercial safety-related applications, such as fire and gas related applications and ESD or emergency shutdown systems. It is programmed using Windows or MS-DOS software and is capable of communicating with I/O modules and smart option modules in the same PLC system on which it is installed via a rack-mounted backplane. The IC697CPM790 programmable controller CPU cannot run unless a stand-alone C program is included as part of the application loaded by the CPU.
