IC754VSI12CTD   GE 12英寸彩色TFT触摸快速面板显示器

IC754VSI12CTD  GE 12英寸彩色TFT触摸快速面板显示器

IC754VSI12CTD允许任何操作员或用户通过提供的监视器、触摸输入接口和通信接口监控或控制连接的机器或过程。为了监控系统，所提供的12英寸彩色薄膜晶体管(TFT)显示屏能够通过定制设计的模拟提供过程的可视化。此外，彩色显示屏支持彩色编码动画和状态显示的实现，以提高信息水平。控制命令通过触摸屏输入，触摸屏允许操作员通过触摸适当的运行时图标或对象直接输入命令。使用单个RS232 / RS485组合端口在点对点或多点串行拓扑中完成与控制器的通信，而通过支持10/100 Mbps传输速率的以太网通信接口完成联网和多节点通信。

IC754VSI12CTD由24VDC外部电源供电，功耗低于48W。当与Proficy Machine Edition 5.0或更高版本一起使用时，此操作面板支持历史数据记录、查看和Visual Basic。

通用电气IC754VSI12CTD终端重量轻，设计为现代接口机QuickPanel组的一部分。IC754VSI12CTD终端使客户能够通过RS-232/RS-485通信端口以及相关的HMI-CAB-C110通信链路，使用Proficy View(机器版)编程软件与其机器进行交互。用户可以利用触摸屏输入数据和信息。

IC754VSI12CTD  GE 12英寸彩色TFT触摸快速面板显示器

The IC754VSI12CTD allows any operator or user to monitor or control a connected machine or process through the provided monitor, touch input interface and communication interface. To monitor the system, the supplied 12-inch color thin-film transistor (TFT) display provides visualization of the process through custom-designed simulations. In addition, the color display supports the implementation of color-coded animation and status display to improve the level of information. Control commands are entered via a touch screen, which allows the operator to enter commands directly by touching the appropriate runtime icon or object. Communication to the controller is accomplished in a point-to-point or multipoint serial topology using a single RS232 / RS485 combination port, while networking and multi-node communication is accomplished through an Ethernet communication interface that supports 10/100 Mbps transmission rates.

The IC754VSI12CTD is powered by a 24VDC external power supply and consumes less than 48W. When used with Proficy Machine Edition 5.0 or later, this action panel supports historical data logging, viewing, and Visual Basic.

The GE IC754VSI12CTD terminal is lightweight and designed as part of the QuickPanel group of modern interface machines. The IC754VSI12CTD terminal enables customers to interact with their machines using Proficy View(Machine Edition) programming software via the RS-232/RS-485 communication port and the associated HMI-CAB-C110 communication link. Users can use the touch screen to enter data and information.

IC754VSI12CTD  GE 12英寸彩色TFT触摸快速面板显示器
