PCD231B101励磁装置主要分为电磁型和半导体型两大类。电磁型励磁装置主要用于以直流或交流励磁机为励磁电源的励磁系统中,半导体型励磁装置既可以与励磁机一起组成静止(或旋转)整流器励磁系统，也可以与励磁变压器组成静止励磁系统。

目前中国出口的励磁装置型号，适用范围及主要构成部分(如表)各生产厂除供应定型产品外，还可根据用户需要进行设计和制造。

PCD231B101按整流方式可分为旋转式励磁和静止式励磁两大类。其中旋转式励磁又包括直流交流和无刷励磁;静止式励磁包括电势源静止励磁机和复合电源静止励磁机。

PCD231B101励磁分类方法很多，比如按照发电动无识别结的交而想原供给方式来分类。

第 一类是由与发电机同轴的交流励磁机供电，称为交流励磁(他励)系统,此系统又可分为四种方式:

1、交流励磁机(磁场旋转)加静止硅整流器(有刷)。

2、交流励磁机(磁场旋转)加静止可控硅整流器(有刷)。

3、交流励磁机(电枢旋转)加硅整流器(无刷)。

4、交流励磁机(电枢旋转)加可控硅整流器(无刷)。

PCD231B101 ABB 模块 半导体型励磁装置

PCD231B101 excitation device is mainly divided into electromagnetic type and semiconductor type two categories. Electromagnetic exciter is mainly used in the excitation system with DC or AC exciter as the excitation power supply, semiconductor exciter can be combined with the exciter to form a static (or rotating) rectifier excitation system, but also with the excitation transformer to form a static excitation system.

At present, China's export of excitation device models, scope of application and main components (as shown in the table) In addition to the supply of fixed products, production plants can also be designed and manufactured according to user needs.

PCD231B101 can be divided into two categories of rotary excitation and static excitation according to the rectification mode. The rotary excitation also includes DC AC and brushless excitation; Static exciter includes potential source static exciter and composite source static exciter.

PCD231B101 excitation classification methods are many, such as according to the generation of no identification junction and the original supply mode to classify.

The first type is powered by an AC exciter coaxial with the generator, called an AC exciter (separate excitation) system, which can be divided into four ways:

1, AC exciter (magnetic field rotation) plus static silicon rectifier (brush).

2, AC exciter (magnetic field rotation) plus static thyristor rectifier (brush).

3, AC exciter (armature rotation) plus silicon rectifier (brushless).

4, AC exciter (armature rotation) plus thyristor rectifier (brushless).
