工业电源模块,包括电源保护壳电源保护壳内安装有工业电源本体电源保护壳的侧壁上设有通气孔,

电源保护壳内设有滤尘网滤尘网内间隔设有多个支撑板相邻的两支撑板之间安装有传热板传热板上设有与通气孔连通的传热孔多个支撑板及传热板围设成矩形空间矩形空间的底部设有印刷电路板

印刷电路板上安装工业电源本体和风扇电源保护壳上可拆卸设有盖板盖板上设有与传热孔连通的二通气孔采用传热板快速导热,并通过风扇将工业电源本体产生的热量,经传热板快速从通气孔和二通气孔释放出去,散热性能较好,可靠性高稳定性强.

PM3398B-6-1-3-E 工业电源模块PIONEER MAGNETICS

The industrial power module includes a power supply protection shell. The industrial power supply body is installed in the power supply protection shell. The side wall of the power supply protection shell is provided with a vent.

A dust filter screen is arranged in the power protection shell. A plurality of support plates are arranged in the space between the two adjacent support plates. A heat transfer plate is arranged between the heat transfer plates and a heat transfer hole is arranged on the heat transfer plate. A plurality of support plates and heat transfer plates are arranged around a rectangular space. A printed circuit board is arranged at the bottom of the rectangular space

The printed circuit board is installed on the industrial power supply body and the fan power supply protection shell is provided with a removable cover plate. The cover plate is provided with a two-vent hole connected with the heat transfer hole. The heat transfer plate is used to conduct heat quickly, and the heat generated by the industrial power supply body is quickly released from the vent hole and the two-vent hole through the heat transfer plate.
