xme -653是Xycom Automation提供的强大的VMEbus PC兼容处理器模块VMEbus PC技术的先驱和领 导者。这功能强大的单槽VMEbus处理器集成

233mhz MMX奔腾CPUPCI-to-VMEbus接口，允许用户采用优势在于强大的多处理能力的VMEbus，同时使用标准现货PC软件和操作系统。

xme -653模块的核心是Intel233MHz MMX CPU结合512K同步2级管道缓存和高达256 MB的内存快页或EDO DRAM。

该模块包含广泛的I/O，包括PCI图形，EIDE和以太网控制器，一个通用串行总线(USB)接口，两个高速串口，一个EPP/ECP并口，PS/2样式键盘和鼠标端口。进一步的I/O扩展可以使用Xycom Automation的模块I/O载波模块(xme -976)，它提供了一个机制扩展您的系统使用PMC, PC/104、短ISA或PCI模块。

XVME-653模块是一种无与伦比的解决方案电源和I/O的单槽VMEbus模块。

XVME-653 VMEbus奔腾处理器模块 数据采集与监视控制系统

The xme-653 is the pioneer and leader in VMEbus PC technology, a powerful VMEbus PC-compatible processor module from Xycom Automation. This powerful single slot VMEbus processor is integrated

The 233mhz MMX Pentium CPUPCI-to-VMEbus interface allows users to take advantage of the VMEbus's powerful multiprocessing capabilities while using standard off-the-shelf PC software and operating systems.

The core of the xme-653 module is the Intel233MHz MMX CPU combined with 512K synchronous level 2 piped cache and up to 256 MB of memory fast page or EDO DRAM.

The module contains a wide range of I/O, including PCI graphics, EIDE and Ethernet controllers, a universal serial bus (USB) interface, two high-speed serial ports, an EPP/ECP parallel port, PS/2 style keyboard and mouse ports. Further I/O extensions can be made using Xycom Automation's Modular I/O Carrier Module (xme-976), which provides a mechanism to extend your system using PMC, PC/104, Short ISA, or PCI modules.

The XVME-653 module is an unmatched solution for power and I/O single-slot VMEbus modules.
